APC IT Power Distribution Module 30A L21-30 260cm

VENDOR: APC Mfg Part#: PDM3530L2130-260 UPC#: 731304272410
1 1
Photo is for illustration purposes only. Actual product may be different.
$1,243.00
$1,243.00
Sale Sold out
MSRP: $1,868.00
Shipping calculated at checkout.
  • 208V AC input and output with 30A max current via NEMA L21-30 connector
  • Compatible with APC Symmetra PX UPS systems (10kW to 100kW)
  • Plug-in automatic circuit breaker with circuit protection
  • Remote management supported via SNMP and HTTP protocols
  • Features LCD display and LED indicators for monitoring
  • Integrated 8.5 ft (260cm) power cable; UL and RoHS compliant

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Designed specifically for scalable APC Symmetra PX deployments, ensuring seamless integration
  • Supports remote power monitoring through SNMP and HTTP, reducing need for onsite diagnostics
  • Compact, compliant, and TAA-certified for reliable deployment in enterprise and government facilities

Product Overview

The APC IT Power Distribution Module (PDM3530L2130-260) is a plug-in automatic circuit breaker that delivers 208V, 30A power via a NEMA L21-30 connector. Supporting 3-phase input, it's designed for Symmetra PX UPS systems ranging from 10kW to 100kW. Equipped with LCD and LED status indicators and remote management via SNMP/HTTP, it ensures ease of monitoring. The compact size and integrated 260cm power cable enable flexible installation in tight IT environments. UL and RoHS compliant with a 1-year warranty and TAA compliance, it meets enterprise-grade reliability and procurement standards.

Specifications

Product Overview
Manufacturer APC
Product Name APC IT Power Distribution Module 30A L21-30 260cm
Manufacturer Part Number PDM3530L2130-260
Product Type Automatic circuit breaker - plug-in module
Form Factor Plug-in module
Power Requirements AC 208V, 60 Hz, 30 A
Power Cable Length 260 cm (8.5 ft)
Circuit Protection Circuit breaker
Designed For UPS Systems APC Symmetra PX 10kW to 100kW scalable systems

Wireless Features
Remote Management Protocols SNMP, HTTP

Compliance & Origin
Compliance Standards UL, RoHS Exemption 7b
TAA Compliance Yes
Country of Origin UNITED STATES
UPC 731304272410

Advanced Security Features
Remote Access Security Requires authentication via Symmetra PX interface

Interfaces
Input Connector Type NEMA L21-30
Output Connector Type NEMA L21-30
Input Voltage AC 208 V
Input Voltage Range AC 200 - 240 V
Output Voltage AC 208 V
Input Wiring 3-phase
Frequency Required 60 Hz
Maximum Electric Current 30 A
Output Connection Details 1 x power NEMA L21-30

Physical & Environmental
Width 17.5 in
Depth 16 in
Height 5 in
Shipping Width 17.5 in
Shipping Depth 16 in
Shipping Height 5 in

Cloud Management & Licensing
Remote Monitoring Support Yes
Cloud Management Interface SNMP, HTTP via Symmetra PX
Management Display Features LCD display, LED indicators
