APC NetShelter Switched Metered Rack PDU 8.6kW 208V 30A L21-30P, 48 Outlet

VENDOR: APC Mfg Part#: APDU10351SM UPC#: 731304439813
1 2
Photo is for illustration purposes only. Actual product may be different.
$4,808.00
$4,808.00
Sale Sold out
MSRP: $7,117.00
Shipping calculated at checkout.
  • 8.6 kW (8600 VA) power capacity at 208V 3-phase
  • Vertical (0U) form factor for high-density rack installations
  • 48 switched metered outlets: supports C13, C15, C19, and C21 connector types
  • 30A input via NEMA L21-30P connector
  • Remote outlet-level monitoring and control
  • TAA compliant and includes 3-year warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers reliable power distribution with 48 metered, switchable outlets, suitable for dense IT environments.
  • Enables precise power management and remote monitoring to reduce downtime and energy costs.
  • Complies with TAA requirements and is manufactured in the USA, supporting government and enterprise deployments.

Product Overview

The APC NetShelter Rack PDU Advanced (APDU10351SM) delivers 8.6kW of 208V 3-phase power across 48 switched metered outlets (C13/C15/C19/C21) via a NEMA L21-30P input. Built for high-density vertical (0U) installations, it offers remote monitoring and per-outlet control to boost energy efficiency and uptime. TAA compliant, made in the USA, and backed by a 3-year warranty, it is ideal for enterprise data centers requiring power flexibility and control.

Specifications

Product Overview
Product Type Switched Metered Rack Power Distribution Unit (PDU)
Model APDU10351SM
Form Factor Vertical (0U)
Color Black
Power Capacity 8.6 kW
Apparent Power (VA) 8600 VA
Input Power Requirements 208 V AC, 3-Phase
Input Current 30 A
Input Plug Type NEMA L21-30P
Mounting Toolless rack mounting capable, vertical mounting (0U)

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications cULus, CE, FCC Class A, VCCI, NOM, RoHS, REACH, EAC, WEEE
Environmental Compliance RoHS, REACH

Advanced Security Features
Access Control Role-based user access control
Network Security SSL/TLS, SSH, SNMPv3 encryption
Logging and Notifications Event logging, email and SNMP trap alerts

Interfaces
Output Receptacles 48 Total (C13, C15, C19, C21 mix)
Total Receptacles 48
Metering Per outlet and aggregate input power metering
Switching Per-outlet switching
Network Port 1 x Ethernet (RJ45)
Expansion Ports 1 x Sensor port, 1 x USB (for firmware updates)

Physical & Environmental
Height 70.08 in (178 cm)
Width 2.2 in (5.6 cm)
Depth 2.95 in (7.5 cm)
Weight 21.38 lbs (9.7 kg)
Operating Temperature 0 to 60 °C (32 to 140 °F)
Storage Temperature -25 to 65 °C (-13 to 149 °F)
Operating Humidity 5 – 95% RH (non-condensing)
Storage Humidity 5 – 95% RH (non-condensing)
Operating Elevation 0 – 3000 m (0 – 10,000 ft)
Storage Elevation 0 – 15000 m (0 – 50,000 ft)

Cloud Management & Licensing
Management Interface Web (HTTP/HTTPS), SNMPv1/v2c/v3, SSH, Telnet
Remote Management Yes, includes outlet-level control and metering
Firmware Upgrade Capability Yes (via USB or network)
Cloud Integration EcoStruxure IT Ready
License Requirements None for basic features, optional for advanced analytics
