APC PDM3450CS50-860 IT Power Distribution Module, 50A, 208V, 3‑Phase

VENDOR: APC Mfg Part#: PDM3450CS50-860 UPC#: 731304281627
1 1
Photo is for illustration purposes only. Actual product may be different.
$2,699.00
$2,699.00
Sale Sold out
MSRP: $4,060.00
Shipping calculated at checkout.
  • Automatic circuit breaker design with plug-in modular form factor
  • 3-phase AC input/output at 208V supports up to 50A max current
  • Integrated 28-foot Hubbell CS8365C power cable
  • LED operational status indicators
  • Compliant with UL and RoHS Exemption 7b standards
  • 1-year limited manufacturer warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Designed for compatibility with APC Symmetra and Modular PDUs for scalable integration
  • Integrated 28 ft power cable and Hubbell connector streamline installation
  • Delivers reliable power protection via built-in circuit breaker with LED indicators

Product Overview

The APC PDM3450CS50-860 IT Power Distribution Module delivers efficient, high-capacity power distribution in enterprise IT and industrial infrastructure environments. It operates on a 3-phase AC input and output voltage of 208V and supports up to 50 amps, making it suitable for high-load equipment and mission-critical power applications. The unit features an integrated 28-foot Hubbell CS8365C power cable, eliminating the need for additional cabling and simplifying installation.

Designed as a plug-in automatic circuit breaker module, this device incorporates circuit protection to guard connected hardware. It includes clear LED indicators for operational status at a glance. The unit is built to meet UL and RoHS Exemption 7b compliance standards and is backed by a 1-year limited warranty, ensuring it meets regulatory and reliability expectations. With compact dimensions (17.5 x 16 x 5 inches) and a weight of 12.57 lbs, it integrates cleanly into dense power infrastructures.

This model is compatible with a wide range of APC Modular Power Distribution units and Symmetra UPS systems, making it a flexible choice in scalable environments. Whether used in large-scale data centers or critical process automation setups, the PDM3450CS50-860 ensures safe, modular, and efficient power deployment.

Specifications

Product Overview
Product Type IT Power Distribution Module
Form Factor Plug-in module
Device Type Automatic circuit breaker - plug-in module
Weight 12.57 lbs
Shipping Weight 13.89 lbs
Power Cable Included Yes, 28 ft integrated Hubbell CS8365C cable
Circuit Protection Integrated circuit breaker
Frequency Required 60 Hz
Max Electric Current 50 A
Input Voltage AC 208 V
Output Voltage AC 208 V
Input Voltage Range (Adjustable) AC 200 - 240 V

Physical & Environmental
Dimensions (W x D x H) 17.5 in x 16 in x 5 in
Width 17.5 in
Depth 16 in
Height 5 in
Shipping Width 17.5 in
Shipping Depth 16 in
Shipping Height 5 in

Cloud Management & Licensing
Manufacturer Warranty 1-year limited warranty
Support Services Limited warranty - 1 year

Compatibility
Designed For PDUs AP7869B, AP7899B, AP7968B, AP7998B, PDPM100F-M, PDPM100L6F-M, PDPM150G6F, PDPM150L6F
Designed For UPS Systems SY10K100F, SY20K100F, SY30K100F, SY40K100F, SY50K100F, SY60K100F, SY70K100F, SY80K100F, SY90K100F, SY100K100F (and -NB variants)
Additional Compatible Units AP7567A, AP7568, AP7569, AP7598, AP7599, PDPM100F6F-M, PDPM100G6F-M, PDPM144F, PDPM72F-5U

Interfaces
Input Connectors Hubbell CS8365C
Input Wiring 3-phase

Compliance & Origin
Country of Origin UNITED STATES
TAA Compliance Yes
Compliance Standards UL, RoHS Exemption 7b

Advanced Security Features
LED Indicators Yes (operational status indicators)
