| Manufacturer | APC |
| Product Name | APC Smart-UPS X-Series External Battery Pack 48V Rackmount 2U |
| Part Number | SMX48RMBP2US |
| Type | External Battery Pack |
| Compatible UPS Voltage | 48V |
| Nominal Output Voltage | 48V DC |
| Battery Capacity | 864 VAh |
| Form Factor | Rack/Tower Convertible |
| Rack Height | 2U |
| Weight | 28.58 kg |
| Color | Black |
| Battery Type | Lead-acid |
| Hot-Swappable Batteries | Yes |
| User-Replaceable Batteries | Yes |
| Maintenance-Free Design | Yes |
| Typical Recharge Time | 3 hours |
| Battery Modules Included | 1 |
APC Smart-UPS X-Series External Battery Pack 48V Rackmount 2U
Photo is for illustration purposes only. Actual product may be different.
Regular price
$1,153.00
Regular price
Sale price
$1,153.00
Unit price
per
MSRP: $1,715.00
Shipping calculated at checkout.
Couldn't load pickup availability
- 48V external battery pack with 864VAh capacity
- 2U rackmount/tower form factor for flexible installation
- Lead-acid battery technology for reliable energy storage
- TAA compliant and manufactured in the United States
- 2-year repair or replace service and support coverage
- Black enclosure with compact dimensions (17.01"W x 19.29"D x 3.5"H)
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Extend UPS runtime with a high-capacity 864VAh 48V external battery module
- Meets TAA compliance standards for eligibility in government and federally contracted installations
- Backed by a 2-year warranty and manufactured in the USA for quality assurance and support
Product Overview
The APC Smart-UPS X-Series External Battery Pack (SMX48RMBP2US) enhances runtime for compatible UPS systems with 48V and 864VAh capacity. It supports both rack and tower mounting in a compact 2U form factor. Featuring lead-acid battery technology, it meets TAA compliance and is backed by a 2-year repair/replacement warranty. Built in the United States and weighing 28.58 kg, it ensures reliable backup for mission-critical equipment.
Specifications
Product Overview
Physical & Environmental
| Width | 17.01 inch |
| Depth | 19.29 inch |
| Height | 3.5 inch |
| Rack Mounting Kit Included | Yes |
| Mounting Options | Rack or Tower |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -15 to 45 °C |
| Operating Relative Humidity | 0 to 95% (non-condensing) |
| Storage Relative Humidity | 0 to 95% (non-condensing) |
| Operating Elevation | 0–3000 m |
| Storage Elevation | 0–15000 m |
| Acoustic noise at 1 meter | <40 dBA |
Cloud Management & Licensing
| SmartSlot Support | Yes (requires compatible UPS with SmartSlot) |
| Remote Monitoring Capability | Available via connected UPS with APC software |
| APC PowerChute Support | Yes (through connected UPS) |
Interfaces
| UPS Connection Type | SMX Series Smart-UPS connection via rear DC connector |
| Expansion Slots | Daisy-chainable for additional external battery packs |
Compliance & Origin
| Country of Origin | United States |
| TAA Compliant | Yes |
| RoHS Compliance | Yes |
| REACH Compliance | Yes |
| Certifications | UL 1778, CSA, CE, FCC Part 15 Class A |
Advanced Security Features
| Battery Management System | Advanced battery management for optimized performance |
| Audible Alarms | Yes, via UPS |
| Overload Protection | Provided by UPS system |
