Belkin 4-Port Dual-Head Secure Modular KVM Switch PP4.0 with Remote

VENDOR: BELKIN Mfg Part#: F1DN204MOD-BA-4 UPC#: 745883789627
1 4
Photo is for illustration purposes only. Actual product may be different.
$693.00
$693.00
Sale Sold out
MSRP: $883.00
Shipping calculated at checkout.
  • Supports up to four host computers for concurrent access
  • Dual-head (two-display) support for enhanced productivity
  • Includes remote-control unit for convenient operation
  • Modular design suitable for varied system architecture
  • TAA-compliant and manufactured in the United States
  • Desktop form factor enables easy integration into workspace

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Designed for secure access to multiple systems in sensitive environments, supporting four computers simultaneously.
  • Dual-display support and modular configuration increase workflow efficiency and deployment flexibility.
  • TAA-compliance and U.S. manufacturing make it suitable for government and regulated industries.

Product Overview

The Belkin 4-Port Dual-Head Modular Secure KVM Switch Base Unit PP4.0 (Model F1DN204MOD-BA-4) provides secure access to up to four host computers and dual-displays for the user. Its desktop form factor and included remote-control unit make it ideal for space-constrained or high-security environments. TAA-compliant and manufactured in the United States, this switch is suited for deployment in enterprise and government infrastructures requiring modular, secure data access.

Specifications

Product Overview
Device Type KVM Switch
Model F1DN204MOD-BA-4
Form Factor Desktop
Number of Computers Supported 4
Number of Displays Supported 2
Remote Control Included Yes
Product Family Secure Modular KVM
Weight 1.95 kg
Power Requirements 12V DC, 3A (external power supply)

Physical & Environmental
Dimensions (W x D x H) 243 x 152 x 44 mm
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Relative Humidity 0% to 80% (non-condensing)
MTBF 457,392 hours
Cooling Passive

Cloud Management & Licensing
Cloud Management Not Supported
Software Licensing Required No
Firmware Update Method Local (via secure interface)

Interfaces
User Console Ports Modular (dependent on installed CAC and video interface modules)
Host Computer Ports Modular (dependent on installed interface modules)
Interface Module Support Supports HDMI, DisplayPort, DVI, USB and CAC module options
Peripheral Sharing Keyboard, Video, Mouse
USB Ports Supports USB keyboard and mouse per channel (via modular interface)
Display Interfaces Supported HDMI, DisplayPort, DVI (via modules)
Console Audio Support No
Console Port Type Modular interface slot (requires interface module)
Keyboard/Mouse Interface USB (via modules)
Remote Port Selector Included (wired)

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certification NIAP PP 4.0 Certified
Security Rating PP4.0 (Protection Profile 4.0)
RoHS Compliance Yes
Lead-Free Status Yes

Advanced Security Features
Tamper Evident Yes
Tamper Resistant Design Yes
Automatic Keyboard Mapping Yes
Unidirectional Data Flow Enforcement Yes
Isolated Data Channels Yes
Non-Reprogrammable ROM Yes
