| Product Type | Layer 3 Managed Stackable Switch |
| Form Factor | Rack-mountable - 1U |
| Weight | 20.59 lbs |
| Power Requirements | AC 120/230 V (50 - 60 Hz) |
| Power Provided | 1100 Watt |
| Power Redundancy | Optional |
| Installed Power Supplies | 1 |
| Maximum Supported Power Supplies | 2 |
| Power Device | Internal power supply - hot-plug |
| MTBF | 202,160 hours |
| Manufacturer Warranty | Limited lifetime warranty |
Cisco C9300-48UXM-1A 48-Port Multigigabit Network Switch
Photo is for illustration purposes only. Actual product may be different.
Regular price
$14,303.00
Regular price
Sale price
$14,303.00
Unit price
per
MSRP: $20,977.00
Shipping calculated at checkout.
Couldn't load pickup availability
- 48-port L3 managed switch with 36 x 2.5GBase-T and 12 x multirate UPOE ports
- Supports advanced routing protocols including OSPFv3, BGP, MPLS, and EIGRP
- Delivering 580 Gbps switching capacity and 480 Gbps stacking bandwidth
- 490W UPOE PoE budget for powering high-demand devices
- Managed remotely via SNMP, NETCONF, RESTCONF, and CLI
- High availability with StackWise-480 technology and optional redundant power
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Delivers high-speed, multigigabit connectivity across 48 ports to meet enterprise-scale bandwidth needs
- Backed by Cisco Network Advantage (1 year), enabling advanced security, routing, and automation features
- Enterprise-class reliability with 202,160-hour MTBF and lifetime hardware replacement warranty
Product Overview
The Cisco C9300-48UXM-1A is a powerful 48-port Layer 3 managed switch built for enterprise-grade networking with high availability, security, and scalability. With a mix of 36 x 2.5GBase-T UPOE ports and 12 multirate ports, this unit is ideal for high-performance access layer deployments. It delivers advanced routing protocols and a 490W PoE budget for connected devices.
Enhanced with Cisco Network Advantage features and standards compliance, it supports routing protocols such as BGP, OSPFv3, and MPLS. Features like Cisco StackWise-480, Flexible NetFlow, and MACsec encryption enable secure and scalable deployments. API support through NETCONF and RESTCONF simplifies remote management.
With a switching capacity of 580 Gbps, a stacking bandwidth of 480 Gbps, and MTBF of over 200,000 hours, the unit ensures performance and reliability. A compact 1U rack-mountable design makes it a space-efficient yet powerful network solution for modern organizations.
Specifications
Product Overview
Wireless Features
| Wireless Support |
Compliance & Origin
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1p, IEEE 802.3at, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s |
| Additional Compliance | RoHS, UL 60950-1, FCC CFR47 Part 15 A, EN 55022 Class A, VCCI Class A, ICES-003 Class A, EN55024, CISPR 22 Class A, CISPR 24 |
| Country of Origin | UNITED STATES |
| TAA Compliant | Yes |
Advanced Security Features
| PoE Type | UPOE |
| PoE Budget | 490 W |
| Routing Protocols | OSPF, OSPFv3, EIGRP, IS-IS, RIPng, RIP-1, RIP-2, BGP, HSRP, IGMP, VRRP, PIM-SM, PIM-SSM, BiDir-PIM, MSDP, Policy-Based Routing (PBR), MPLS |
| MAC Security (MACsec) | Supported |
| Encryption Algorithm | 128-bit AES |
| Access Control | 802.1x authentication, ACL support |
| Other Security Features | Private VLAN, VLAN Double Tagging (Q-in-Q), SGT caching, Control Plane Policing (CoPP), TrustSec, FTP client, VRF, NSF |
Interfaces
| Total Ports | 48 |
| Port Configuration | 36 x 2.5GBase-T (UPOE) + 12 x multigigabit (100/1000/2.5G/5G/10G) UPOE |
| Interface Types | RJ-45 Ethernet + 1 x USB 2.0 |
| Expansion Slots | 1 (total) / 1 (free) x expansion module slot |
| Switching Capacity | 580 Gbps |
| Stacking Bandwidth | 480 Gbps |
| Forwarding Rate | 431.54 Mpps |
| Jumbo Frames Support | 9198 bytes |
| Packet Buffer Size | 32 MB |
Physical & Environmental
| Dimensions (W x D x H) | 17.5 in x 22.2 in x 1.7 in |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 113 °F |
| Humidity Operating Range | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Storage Range | 5 - 90% (non-condensing) |
| Status Indicators | Status |
| Cooling Fans | 3 fans integrated |
Cloud Management & Licensing
| Management Interface | CLI, SNMP versions 1/2c/3, RMON 1/2, NETCONF, RESTCONF |
| Software License Included | Cisco Network Advantage (1 year) |
| Remote Management Features | Flexible NetFlow, integrated Wireshark, CoAP, SGT caching |
