Cisco Catalyst 9164I Access Point W6E Tri-Band 4x4

VENDOR: CISCO Mfg Part#: CW9164I-B UPC#: 889728464017
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,803.00
$1,803.00
Sale Sold out
MSRP: $3,101.00
Shipping calculated at checkout.
  • Tri-band radio with support for 2.4 GHz, 5 GHz, and 6 GHz frequency bands
  • 802.11ax (Wi-Fi 6 and Wi-Fi 6E), Bluetooth 5.1, and 4x4 MIMO support
  • 2.5 Gbps data transfer rate with Multigigabit Ethernet port
  • 2048 MB DRAM and 1024 MB flash memory for robust performance and storage
  • Omnidirectional antenna for versatile coverage in indoor environments
  • Limited lifetime hardware warranty for long-term operational reliability

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports next-generation Wi-Fi 6E for expanded bandwidth and future-proof connectivity
  • High-speed 2.5 Gbps Multigigabit Ethernet ensures optimal data throughput in enterprise environments
  • Limited lifetime hardware warranty provides long-term value and reduced TCO

Product Overview

The Cisco Catalyst 9164I Access Point (CW9164I-B) is a high-capacity tri-band wireless access point built for modern enterprise wireless infrastructure. Featuring Wi-Fi 6/6E (802.11ax), Bluetooth 5.1, and a 4x4 MIMO layout, it supports strong multi-user throughput on the 2.4 GHz, 5 GHz, and 6 GHz bands. It includes a 2.5 Gbps Multigigabit Ethernet port, RJ-45 console management, and USB 2.0 connectivity. With 2048 MB DRAM and 1024 MB flash memory, it ensures consistent performance and firmware scalability. The included omnidirectional antenna and limited lifetime warranty support enterprise reliability and scalability.

Specifications

Product Overview
Product Type Access Point
Model Cisco Catalyst 9164I
Form Factor Ceiling-mountable or wall-mountable
RAM 2048 MB
Flash Memory 1024 MB
Power Device Type DC Adapter or PoE
Power Voltage Required 54V DC
MIMO Type 4x4 MIMO
Antenna Type Omni-directional internal antennas
Service & Support Type Limited lifetime hardware warranty

Wireless Features
Wireless Standards 802.11a/b/g/n/ac/ax (Wi-Fi 6/6E)
Wi-Fi Generation Wi-Fi 6E
Bluetooth Version Bluetooth 5.1
Radio Count 3 (Tri-radio)
Supported Frequency Bands 2.4 GHz, 5 GHz, 6 GHz
Max Wireless Throughput (Theoretical) Up to 5.4 Gbps

Compliance & Origin
Country of Origin China / Mexico
Compliance Standards IEEE 802.3ab, 802.3af/at/bt, IEEE 802.11a/b/g/n/ac/ax, IEEE 802.11h/d
Certifications UL, FCC, IC, European CE, RCM, VCCI, BSMI, NCC, MSIP

Advanced Security Features
Wireless Security Features WPA3, WPA2, WPA Enterprise, 802.1X authentication, Rogue AP Detection
Integrated Security Basic IDS/IPS, Client isolation, Secure Boot, Secure firmware updates

Interfaces
Interface Types 1x 100M/1G/2.5G Multigigabit Ethernet (RJ-45), 1x RJ-45 Console Port, 1x USB 2.0
Port Count 3
Data Transfer Rate 2.5 Gbps
Data Link Protocols Gigabit Ethernet, Wi-Fi, Bluetooth 5.1
Transport Protocol Gigabit Ethernet

Physical & Environmental
Width 9.5 in (24.13 cm)
Depth 9.5 in (24.13 cm)
Height 2.2 in (5.59 cm)
Weight Approximately 1.5 kg (3.31 lbs)
Mounting Options Ceiling mount, Wall mount
Operating Temperature Range 0°C to 40°C (32°F to 104°F)
Operating Humidity Range 10% to 90% (non-condensing)

Cloud Management & Licensing
Management Interface Cisco Meraki Dashboard / CLI via console / Web UI (when supported)
Licensing Model Subscription-based via Cisco DNA or Meraki cloud licensing
Included Cloud Management Requires Cisco Meraki or DNA license (sold separately)
