Cisco Catalyst 9300-24T-1A 24-Port Managed Stackable Switch

VENDOR: CISCO Mfg Part#: C9300-24T-1A UPC#: 889728135627
  • The Cisco Catalyst 9300-24T-1A offers 24 non-PoE Gigabit Ethernet ports and high switching capacity, making it ideal for modern enterprise campus environments. With built-in advanced Layer 3 features, Dual-stack IPv4/IPv6 support, and Cisco’s Network Advantage license, it supports scalable deployments with high security and performance reliability.
1 1
Photo is for illustration purposes only. Actual product may be different.
$7,181.00
$7,181.00
Sale Sold out
MSRP: $10,140.00
Shipping calculated at checkout.
  • 24 x 10/100/1000 Ethernet ports with rack-mountable 1U form factor
  • 480 Gbps stacking bandwidth and 128 Gbps switching capacity
  • 8 GB RAM and 16 GB Flash memory for operational efficiency
  • Comprehensive Layer 3 protocol support including OSPF, VRRP, and PBR
  • Advanced security: 802.1X, port security, DHCP snooping, AES encryption
  • Hot-pluggable 350 W internal power supply with optional redundancy
View full details

Key Benefits

Eye-Insights
  • Designed for scalability and performance with 480 Gbps stacking bandwidth and Layer 3 routing support
  • Offers enterprise-grade security with 128-bit AES encryption and 802.1X access control
  • Reliable long-term investment backed by 314,790-hour MTBF and Cisco IOS XE capabilities

Product Overview

The Cisco Catalyst 9300-24T-1A is a 24-port Gigabit Ethernet managed switch ideal for campus networks requiring high availability, scale, and security. With 480 Gbps stacking bandwidth and 128 Gbps switching capacity, it supports Layer 3 advanced routing including OSPF, VRRP, and PIM. Featuring 8 GB RAM and 16 GB Flash memory, it comes with one hot-pluggable 350 W internal power supply, a second optional for redundancy. Security features include 128-bit AES encryption, 802.1X authentication, port security, and CoPP. Management is enhanced via Cisco IOS XE, with Flexible NetFlow (64K entries) and integration tools like Wireshark. Certified and TAA-compliant, it ensures long-term reliability and standards adherence, making it a high-ROI core access solution.

Specifications

Primary Information
Network Device Type Switch
Model C9300-24T-1A
Connectivity Technology Wired
Data Transfer Rate 1 Gbps
Data Link Protocol Gigabit Ethernet
RAM / Total Installed Size 8 GB
Flash Memory / Installed Size 16 GB
Networking Compliant Standards IEEE 802.3, IEEE 802.1s, IEEE 802.1ba
Power / Device Type Power Supply
Media Layer Supported Layer 2 and Layer 3
Power / Voltage Required 115Vac
MTBF 314790 hours
Features Automated device provisioning; API-driven configuration; Granular visibility; Seamless software upgrades and patching
Status Indicators LED indicators
Power / Provided (W) 350 Watt

Interfaces / Ports
Interfaces 24-port 1G copper with modular uplinks

Service&Support
Service & Support Type 1 year Warranty

UNSPSC Code
UNSPSC Code 43222612

Network
Power Over Ethernet (PoE) Support none
PoE Power Consumption none
MAC Address Table Size 32000
Jumbo Frame Support 9198 bytes
Remote Management Protocol DHCP; IPv6; SNMP
Encryption Algorithm AES
Interfaces 24-port 1G copper with modular uplinks
Routing Protocol RIPv1, RIPv2, RIPng,OSPF

Dimensions&Miscellaneous
Width 17.5 Inch
Depth 16.1 Inch
Height 1.73 Inch
Weight 7.27 Kg

Special Feature
Min Operating Temperature -5 Celsius
Min Storage Temperature -40 Celsius
Max Storage Temperature 70 Celsius
COO UNITED STATES
TAA compliance Yes
RoHS Y
