Cisco ESS3300 GE Bundle Air-Cooled NE, 2x10G + 24xGE

VENDOR: CISCO Mfg Part#: ESS-3300-24T-NCP-E UPC#: 889728166379
  • Embedded Service Series 3000 GE bundle
1 1
Photo is for illustration purposes only. Actual product may be different.
$4,076.00
$4,076.00
Sale Sold out
MSRP: $5,977.00
Shipping calculated at checkout.
  • 2 ports of 1G/10G Ethernet supporting copper or fiber connectivity
  • 4 1G combo ports supporting multiple transceiver and copper standards
  • 4 ports of 1000BaseT/100Base-TX/10Base-T
  • Expansion module with 16 additional Gigabit Ethernet ports
  • Air-cooled design suitable for embedded or enclosed environments
  • RS-232 and USB console interfaces for administration

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers 24-port flexibility with high-density GE and 10G interfaces for complex embedded networking needs
  • TAA compliance and 1-year limited warranty make it ideal for regulated and government applications
  • Designed and manufactured in Mexico, ensuring supply chain reliability for North American projects

Product Overview

The Cisco Embedded Service Series 3300 GE Bundle (ESS3300) is a high-performance, air-cooled solution optimized for embedded network applications. It features 2 full 1G/10G ports, 4 1G combo ports, and 4 fixed 1G copper ports on the main board, with an additional 16 GE ports via expansion—totaling 24 Ethernet ports. Console access via RS-232 and USB adds flexibility in system management. TAA-compliant and backed by a 1-year limited hardware warranty, this product is a secure, scalable option for embedded networking applications.

Specifications

Product Overview
Product Type Embedded Managed Ethernet Switch
Series Cisco Embedded Service Switch 3300 (ESS3300)
Model Number ESS-3300-24T-NCP-E
Form Factor Embedded / Air-cooled module
Power Requirements 12V DC nominal
Power Consumption Typical: ~20W, Maximum: <50W
Cooling Type Air-cooled
Included Accessories None (board-level product)

Physical & Environmental
Dimensions (W x D x H) 127 mm x 177 mm x 41 mm
Weight 0.68 kg (1.5 lbs)
Operating Temperature Range -40°C to +65°C
Storage Temperature -40°C to +85°C
Operating Humidity 5% to 95% (non-condensing)
Storage Humidity 5% to 95% (non-condensing)
MTBF >500,000 hours (est.)

Cloud Management & Licensing
Centralized Management Supported via Cisco DNA Center (optional)
CLI Access Yes
Software Licensing Base image included, enhanced features via license
SNMP Support Yes, v1/v2c/v3
Supported Protocols L2 switching, VLANs, STP, MSTP, IGMP
Monitoring Tools Syslog, SNMP traps, RMON

Interfaces
Total Ethernet Ports 24
10-Gigabit Ethernet Ports 2 x 1G/10G (copper or fiber)
Gigabit Combo Ports 4 x 1G combo (RJ-45 or SFP)
Gigabit Copper Ports 4 x 1000Base-T
Expansion Ports 16 x GE via expansion headers
Console Ports RS-232 and USB
USB Interface 1 x USB Type B console
Serial Interface 1 x RS-232 Console (RJ-45)
Data Transfer Rate Up to 10 Gbps per port

Compliance & Origin
Country of Origin (COO) Mexico
TAA Compliant Yes
UL Certification Yes, UL/CSA recognized
RoHS Compliance Yes
EMC Compliance FCC Class A, EN55032 Class A
CB Scheme IEC/EN/UL/CSA 60950-1, 62368-1
Warranty 1-year Limited Hardware Warranty

Advanced Security Features
MACsec Encryption Supported on select interfaces
Access Control Lists (ACLs) Yes, Ingress and Egress
DHCP Snooping Yes
Dynamic ARP Inspection (DAI) Yes
IP Source Guard Yes
802.1X Port-based Authentication Yes
