Cisco Intel P4510 4TB U.2 NVMe SSD for HyperFlex M5 Series

VENDOR: CISCO Mfg Part#: HX-NVME2H-I4000=
1 3
Photo is for illustration purposes only. Actual product may be different.
$10,996.00
$10,996.00
Sale Sold out
MSRP: $19,886.00
Shipping calculated at checkout.
  • 4TB storage capacity in a 2.5" U.2 form factor
  • U.2 PCIe (NVMe) interface for high-speed data transfer
  • Value Endurance and High Performance class SSD
  • Hot-swappable design for minimal service downtime
  • TAA compliant and manufactured in China/Taiwan
  • Compatible with Cisco HyperFlex and UCS M5 systems

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Optimized for Cisco HyperFlex and UCS M5 platforms, ensuring seamless integration
  • Delivers high-speed NVMe performance with enterprise-grade reliability for critical workloads
  • Hot-swap functionality reduces maintenance interruption and helps maintain system uptime

Product Overview

The Cisco Intel P4510 4TB U.2 NVMe SSD is a hot-swappable, high-performance storage solution designed for enterprise workloads. With 4TB capacity and a U.2 PCIe NVMe interface, it delivers fast data access and low latency. Engineered for Value Endurance, it meets performance needs over time while maintaining cost-efficiency. Compatible with a wide range of Cisco HyperFlex and UCS M5 systems, it offers TAA compliance and reliable integration for government and enterprise deployments.

Specifications

Product Overview
Type Solid state drive - hot-swap
Form Factor 2.5"
Device Type Solid state drive - hot-swap
Capacity 4 TB
Features Value Endurance, High Performance
Weight 150 g
Power Requirements 5V / 12V DC

Physical & Environmental
Dimensions (W x D x H) 69.85 mm x 100.45 mm x 15 mm
Operating Temperature (Min) 0°C
Operating Temperature (Max) 70°C
Storage Temperature (Min) -40°C
Storage Temperature (Max) 85°C
Humidity Range (Operating) 5% – 95% (non-condensing)
Shock Resistance (Operating) 1000G for 0.5 ms
Vibration (Operating) 2.17 GRMS (5-700 Hz)

Cloud Management & Licensing
Software/Management Integration Cisco HyperFlex System and Cisco UCS Manager
Licensing Requirements None for basic usage

Interfaces
Interface U.2 PCIe (NVMe)
Interfaces 1 x PCI Express U.2 (NVMe)
Interface Bus PCI Express 3.1 x4
Data Transfer Rate Up to 3200 MB/s (read), Up to 3000 MB/s (write)
IOPS (Read) Up to 637,000 IOPS
IOPS (Write) Up to 139,500 IOPS
Latency (Read) 10 µs
Latency (Write) 18 µs
Compatible Bay 2.5"

Compliance & Origin
Country of Origin CHINA / TAIWAN
TAA Compliance Yes
RoHS Compliance Yes
Certifications UL, CE, FCC, VCCI, BSMI, KCC

Advanced Security Features
Data Protection End-to-end data protection with CRC
Encryption AES 256-bit Self-Encrypting Drive (SED)
Security Features TCG Opal 2.0, IEEE 1667
