Cisco IW-ANT-PNL5615-NS 5/6GHz 15dBi Panel Antenna, N Connector

VENDOR: CISCO Mfg Part#: IW-ANT-PNL5615-NS=
1 3
Photo is for illustration purposes only. Actual product may be different.
$760.00
$760.00
Sale Sold out
MSRP: $1,114.00
Shipping calculated at checkout.
  • 15dBi antenna gain for extended directional coverage
  • Supports both 5 GHz and 6 GHz frequency bands
  • Two N-Type connectors for flexible installation and MIMO setups
  • Panel form factor for focused signal propagation
  • TAA compliant for use in regulated environments
  • Manufactured in China

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Delivers high-gain directional coverage ideal for long-range or point-to-point wireless applications
  • Equipped with dual N-Type connectors, enabling versatile installation and MIMO configurations
  • TAA compliance ensures suitability for government and enterprise sector purchasing

Product Overview

The Cisco IW-ANT-PNL5615-NS is a high-gain panel antenna engineered for enterprise-grade wireless networking in the 5 GHz and 6 GHz frequency bands. Offering 15dBi gain and dual N-type connectors for MIMO support, it enables precise, extended coverage ideal for point-to-point and high-density deployments. Its TAA compliance and directional design make it well-suited for regulated or interference-sensitive environments.

Specifications

Product Overview
Product Type Directional Panel Antenna
Application Enterprise Wireless Networking
Form Factor Panel
Gain 15 dBi
Number of Antenna Ports 2
MIMO Support 2x2 MIMO
Connector Type N-Type Female
Power Handling Capacity 2 Watts (CW)
Polarization Linear, Vertical and Horizontal
Mounting Type Wall / Pole mount kit included
Directionality Directional

Wireless Features
Supported Frequency Bands 5 GHz, 6 GHz
Wi-Fi Standards Compatibility 802.11a/n/ac/ax
Beamwidth (Horizontal) 35°
Beamwidth (Vertical) 30°
Maximum VSWR 2.0:1
Impedance 50 Ohms
Antenna Coverage Type Directional (Narrow Beam)

Compliance & Origin
Country of Origin China
TAA Compliant Yes
RoHS Compliance Yes
Certification Standards CE, FCC

Advanced Security Features
Security Functions

Interfaces
Number of Connectors 2
Connector Gender Female
Connector Interface Type N-Type

Physical & Environmental
Width 242 mm
Height 242 mm
Depth 55 mm
Product Weight 2.2 lbs (1.0 kg)
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +85°C
Storage Humidity 5% to 95% noncondensing
Ingress Protection Rating IP67
Environmental Rating Outdoor

Cloud Management & Licensing
Cloud Management
Licensing Requirements
