Cisco Nexus 3524-XL 24-Port SFP+ Switch, Extended Memory

VENDOR: CISCO Mfg Part#: N3K-C3524P-XL UPC#: 889728089821
  • Cisco Nexus 3500 Series Switch
1 1
Photo is for illustration purposes only. Actual product may be different.
$18,018.00
$18,018.00
Sale Sold out
MSRP: $26,426.00
Shipping calculated at checkout.
  • 24 SFP+ ports for high-speed 10GbE connectivity
  • Extended memory enhances scalability and performance
  • Part of the Cisco Nexus 3500 Series for consistent architecture
  • TAA compliant for use in government and regulated industries
  • Manufactured in China, Mexico, or the United States

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports high-performance 10GbE infrastructure with 24 SFP+ ports
  • TAA compliance ensures eligibility for government or enterprise procurement
  • Enhanced memory supports advanced networking capabilities and scalability

Product Overview

The Cisco Nexus 3524-XL is part of the Cisco Nexus 3500 Series, engineered for high-speed, low-latency switching in modern data centers. With 24 SFP+ ports offering 10Gbps connectivity and extended onboard memory, it’s ideal for scalable, high-density environments. The switch is also TAA compliant and manufactured across CHINA, MEXICO, and the UNITED STATES, making it a fit for regulated industries and government procurement. Optimized for investment protection and future flexibility, the N3K-C3524P-XL plays a vital role in enterprise and virtualized infrastructure deployments.

Specifications

Product Overview
Product Type Managed Ethernet Switch
Series Cisco Nexus 3500 Series
Model Nexus 3524-XL
Form Factor Rack-mountable
Rack Units 1U
Weight 16.5 lbs (7.5 kg)
Power Supply Type Redundant hot-swappable AC or DC power supplies
Power Consumption (Typical) 134 Watts
Power Consumption (Maximum) 180 Watts
Memory (DRAM) 8 GB (Extended Memory)
Flash Memory 2 GB
Forwarding Rate 360 Mpps
Switching Capacity 480 Gbps

Physical & Environmental
Dimensions (H x W x D) 1.72 x 17.3 x 22.0 in (4.4 x 43.9 x 55.9 cm)
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Relative Humidity (Operating) 5% to 95% non-condensing
Relative Humidity (Storage) 5% to 95% non-condensing
Cooling Method Front-to-back or back-to-front airflow (field-replaceable fans)
Acoustic Noise 61.2 dB (typical)

Cloud Management & Licensing
Management Interface Cisco NX-OS CLI, SNMP, REST API
Cloud Management Supported via Cisco Data Center Network Manager (DCNM)
Licensing Model Cisco Smart Licensing
Included Features Advanced buffering, latency monitoring (ALG), flow visibility (telemetry)

Interfaces
Total Number of Ports 24
Port Type 10 Gigabit Ethernet SFP+
Uplink Ports 4 x 40 GbE QSFP+
Console Ports 1 x RJ-45 console port
Management Ports 1 x 10/100/1000BASE-T port
USB Ports 1 x USB Type-A (for file management)
Data Transfer Rate per Port 10 Gbps (SFP+), 40 Gbps (QSFP+)
Aggregate Throughput 480 Gbps full duplex

Compliance & Origin
TAA Compliance Yes
Country of Origin CHINA / MEXICO / UNITED STATES
RoHS Compliance Yes
Certifications UL, CSA, CE, FCC Part 15 Class A, IEC60950-1, NEBS Level 3
Green Compliance Yes

Advanced Security Features
Access Control Role-based access control (RBAC)
Authentication Methods TACACS+, RADIUS, SSHv2, SNMPv3
Port Security Yes
DHCP Snooping Yes
IP Source Guard Yes
Dynamic ARP Inspection Yes
Storm Control Yes
