Cisco UCS C240 M6 Rack Server Chassis - 2U, 12 LFF Bays

VENDOR: CISCO Mfg Part#: HX-C240-M6L
  • The Cisco UCS C240 M6 Rack Server Chassis (HX-C240-M6L) is a 2U, enterprise-ready rackmount server designed for flexible scaling with 12 hot-swap LFF 3.5" bays and dual-CPU capability. It comes without pre-installed CPUs, memory, or drives, allowing businesses to fully customize for specific workloads. With built-in Gigabit Ethernet, advanced management via Cisco IMC, and an optional redundant power setup, it is ideal for scalable data center and virtualization environments.
1 1
Photo is for illustration purposes only. Actual product may be different.
$6,300.00
$6,300.00
Sale Sold out
MSRP: $10,197.00
Shipping calculated at checkout.
  • 2U rack-mountable chassis with 12 hot-swap 3.5" SAS/SATA drive bays
  • Supports up to 2 CPUs (upgradable) and features 32 DDR4 DIMM slots
  • Integrated 1GbE and 10GbE LAN ports for versatile networking
  • Features Intel BMC and Cisco IMC for remote management
  • Optional 1+1 redundant hot-plug power supplies
  • Includes Matrox G200e graphics with VGA output
View full details

Key Benefits

Eye-Insights
  • Highly scalable with capacity for dual CPUs and up to 32 memory modules for demanding workloads
  • Hot-swappable 3.5" LFF bays provide easy access and maintenance of high-capacity storage drives
  • Built-in remote management via Cisco IMC and BMC enhances system uptime and simplifies deployment

Product Overview

The Cisco UCS C240 M6 is a high-density 2U rackmount server chassis designed for robust scalability with dual-CPU support and 12 hot-swappable LFF bays. Featuring 32 empty DIMM slots for DDR4 memory and expandable with mLOM and M.2 card slots, it is built to scale for virtualization and storage-intensive workloads. Integrated Gigabit and 10 Gigabit Ethernet interfaces allow flexible networking, while redundant power support increases uptime. The unit includes advanced management capabilities via Cisco IMC and Intel BMC, and its TAA compliance positions it well for government and enterprise deployments.

Specifications

Primary Information
Model HX-C240-M6L
Processor / Type None Processor
Power / Device Type Power Supply
System Type Server Chassis
Cabinet Form Factor 2U
Processor / Manufacturer Not Included
Processor / Max Supported Qty 2
Mainboard / Chipset Type Intel C621
RAM / Technology DDR4
RAM / Total Slots Qty 32
Data Link Protocol Gigabit Ethernet
Interfaces & Connections One 1Gbase-T RJ-45 management port; Two 10Gbase-T LOM ports; One RS-232 serial port (RJ-45 connector); One DB15 VGA connector; Two USB 3.0 ports; KVM console connector that supplies:two USB 2.0 connectors,one VGA DB15 video connector, one serial port (RS232) RJ45 connector.
Width 16.9 Inch
Height 3.4 Inch
Hard Drive / Interface Type SAS/SATA
Depth 29.5 Inch
Hard Drive / Size 3.5"
Hard Drive / Bays Qty 12
RAID Level RAID 0, 1, 5, 6, 10, 50, 60
Expansion Slots Total (Free) Riser 1B (1 PCIe slot reserved for a drive controller and 2 HDD slots); Riser 2A (3 PCIe slots); Riser 3B (2 HDD slots)

UNSPSC Code
UNSPSC Code 43211502

Special Feature
COO UNITED STATES
TAA compliance Yes
