Cisco UCSX Fabric Interconnect 6536 100Gbps 1U Switch, 38 Ports

VENDOR: CISCO Mfg Part#: UCSX-FI-6536-U
1 3
Photo is for illustration purposes only. Actual product may be different.
$27,329.00
$27,329.00
Sale Sold out
MSRP: $49,424.00
Shipping calculated at checkout.
  • 36 x 40/100-Gbps QSFP28 ports for ultra-high bandwidth connectivity
  • MAC address table supports up to 32,000 entries
  • Support for jumbo frames up to 9216 bytes for optimized data transfer
  • 32 GB installed RAM and quad-core processor for robust management
  • Layer 2 switching with IEEE 802.1s, 802.1w, 802.1q, 802.1x compliance
  • Managed via Cisco UCS Manager and Intersight for centralized control

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers up to 100 Gbps per port across 36 QSFP28 interfaces for high-speed data center workloads
  • Integrated with Cisco UCS Manager/Intersight for simplified infrastructure orchestration
  • Built in the U.S. with RoHS and TAA compliance for government and regulated deployments

Product Overview

The Cisco UCSX Fabric Interconnect 6536 is an enterprise-class, high-speed switch tailored for integrated infrastructure like Cisco UCS. With 36 40/100-Gbps QSFP28 ports and support for jumbo frames up to 9216 bytes, it delivers scalable, low-latency networking. Designed with full Layer 2 compliance and managed through Cisco UCS Manager or Intersight, it enhances orchestration and visibility. A quad-core processor and 32 GB RAM ensure strong management responsiveness, while its MAC address table size of 32,000 supports dense traffic environments. RoHS and TAA compliance coupled with U.S. manufacturing underscore its reliability for critical deployments.

Specifications

Product Overview
Product Type Enterprise-Class Switch
Model Fabric Interconnect 6536
Form Factor 1U
Weight 11.6 Kg
Power Requirements AC 100-240V, 50/60 Hz (via redundant power supplies)
Power Consumption (Typical) Up to 395W
Processor Type Quad-Core
RAM Installed 32 GB
MAC Address Table Size 32000 Entries

Wireless Features
Wireless Support

Compliance & Origin
RoHS Compliant Yes
TAA Compliant Yes
Country of Origin United States
Certifications UL, CSA, CE Marking, FCC Part 15 Class A
Networking Compliance Standards IEEE 802.1s, 802.1w, 802.1p, 802.1x, 802.1q

Advanced Security Features
Secure Boot Yes
Role-Based Access Control (RBAC) Yes
AAA Support Yes (RADIUS, TACACS+)
Policy-Based Network Control Yes

Interfaces
Number of Ports 38 Total
QSFP28 Ports 36 x 40/100-Gbps
Management Ports 1 x 1Gb Ethernet (RJ-45), 1 x RJ-45 Console, 1 x USB
Data Transfer Rate 100 Gbps (per port)
Connectivity Technology Wired
Data Link Protocols Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet
Jumbo Frame Support Up to 9216 bytes
Media Layer Supported Layer 2
Switching Capacity 7.2 Tbps
Forwarding Rate 2.6 Bpps (billion packets per second)

Physical & Environmental
Width 17.3 Inches
Depth 24.7 Inches
Height 1.72 Inches
Minimum Operating Temperature 0°C
Maximum Operating Temperature 40°C
Operating Humidity Range 5% to 95% (non-condensing)
Cooling Type Front-to-rear airflow with redundant fans

Cloud Management & Licensing
Management Interface Cisco UCS Manager, Cisco Intersight
Cloud Management Cisco Intersight (optional subscription)
Licensing Smart Licensing enabled
Included Management Features Centralized orchestration, network visibility, policy enforcement
