D-Link DGS-1250-28XMP-6KV Smart Managed PoE Switch with 10G Uplinks

VENDOR: D-LINK Mfg Part#: DGS-1250-28XMP-6KV UPC#: 790069458828
1 3
Photo is for illustration purposes only. Actual product may be different.
$745.00
$745.00
Sale Sold out
MSRP: $970.00
Shipping calculated at checkout.
  • 28-port Gigabit PoE switch including 4 10G SFP+ ports
  • 370W PoE power budget across 24 ports
  • Supports Layer 2 and Layer 3 static routing (IPv4 and IPv6)
  • D-Link Network Assistant, Web UI, SNMP, and CLI management
  • 12,000-byte jumbo frame support and 16K MAC address table
  • Wide operating temperature (-5°C to 50°C) and MTBF of 463,430.16 hours

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Provides advanced network management via SNMP, Web UI, D-Link DNA utility, and full CLI, ensuring administrative flexibility.
  • Includes 4 x 10G SFP+ uplinks for seamless high-throughput backbone connectivity, future-proofing network builds.
  • Backed by a lifetime warranty with next-business-day replacement, reducing long-term operational risk and costs.

Product Overview

The D-Link DGS-1250-28XMP-6KV Smart Managed PoE Switch is engineered for businesses seeking scalable and high-performance network infrastructure. This 28-port Gigabit Ethernet switch includes 24 PoE ports with 370W total power and 4 10G SFP+ uplink ports, perfect for fast backbone connectivity. With jumbo frame support (12,000 bytes) and a 16K MAC address table, it accommodates high-volume network traffic efficiently.

Offering Layer 2 and Layer 3 static routing with 124 IPv4 and 50 IPv6 routes, this switch is easily managed through a Web UI, D-Link Network Assistant, SNMP, or full CLI access. Security is enforced with RADIUS and MD5 authentication, while the lifetime warranty with next-business-day replacement adds peace of mind. Built for reliability, it operates in diverse temperatures and has an MTBF of over 463,000 hours, making it ideal for mid-sized enterprise environments.

Specifications

Product Overview
Manufacturer D-LINK
Model DGS-1250-28XMP-6KV
Product Type Smart Managed PoE Switch
Form Factor Rack-mountable 1U
Weight 3.46 Kg
Power Requirements 100–240 VAC
Max Power Consumption 455.1 Watt
PoE Power Budget 370W
Power Supply Internal
RAM 256 MB
Flash Memory 64 MB
Jumbo Frame Support 12000 bytes
MTBF 463430.16 hours

Wireless Features

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications FCC, CE, VCCI, BSMI, CCC, RCM

Advanced Security Features
Authentication Methods RADIUS, MD5
Access Control 802.1X Port-based Access Control
Security Protocols SSL, SSH
Storm Control Broadcast/Multicast/Unknown Unicast
DoS Protection Yes
Static Routing Support 124 IPv4, 50 IPv6 routes

Interfaces
Total Ports 28
10/100/1000BASE-T Ports 24
SFP+ 10G Uplink Ports 4
MAC Address Table 16K entries
Data Link Protocol Gigabit Ethernet
Data Transfer Rate 10 Gbps
Media Layer Supported Layer 2, Layer 3
IEEE Standards Compliance IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3az, IEEE 802.3af/at

Physical & Environmental
Width 9.84 Inch
Depth 17.32 Inch
Height 1.73 Inch
Min Operating Temperature -5 °C
Max Operating Temperature 50 °C
Min Storage Temperature -20 °C
Max Storage Temperature 70 °C
Operating Humidity 10% to 90% (non-condensing)

Cloud Management & Licensing
Management Interfaces Web UI, CLI, SNMP, D-Link Network Assistant
Remote Management Protocols SNMP, DHCP, Telnet
Cloud Management Compatible with D-View 7.0
Management Features Built-in SNMP MIB, full CLI support, multilingual Web UI
Warranty & Support Lifetime Warranty with Next Business Day Replacement
