DURABOOK SSDUP-1TB-R8 1TB PCIe SSD Upgrade for R8

VENDOR: DURABOOK Mfg Part#: SSDUP-1TB-R8
1 4
Photo is for illustration purposes only. Actual product may be different.
$1,209.00
$1,209.00
Sale Sold out
MSRP: $1,257.00
Shipping calculated at checkout.
  • 1TB PCIe Solid State Drive for expanded high-speed storage
  • Designed specifically for DURABOOK R8 rugged tablets
  • PCI Express interface for faster data transfer
  • TAA compliant for use in government applications
  • Manufactured in Taiwan for component quality assurance

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Boosts DURABOOK R8 system performance with a 1TB high-speed PCIe SSD upgrade
  • Meets TAA compliance for compatibility with government procurement standards
  • Engineered specifically for the R8 series to ensure flawless integration and stability

Product Overview

The DURABOOK SSDUP-1TB-R8 is a 1TB PCIe Solid State Drive upgrade built for use with the DURABOOK R8 series of rugged tablets. Offering high-speed data transfer via the PCI Express interface, this drive supports faster system performance and multitasking. Manufactured in Taiwan and TAA compliant, it meets stringent procurement and reliability standards. Ideal for high-volume data workflows in industrial or governmental applications, this SSD ensures rugged performance without compromise.

Specifications

Product Overview
Product Type Internal Solid State Drive (SSD) Upgrade
Compatible Device DURABOOK R8 Rugged Tablet
Form Factor M.2 2280
Capacity 1 TB
Power Consumption (Active) 6.5 W (typical)
Power Consumption (Idle) 0.05 W (typical)
Drive Type NVMe PCIe SSD

Physical & Environmental
Drive Dimensions 22 mm x 80 mm x 2.3 mm
Operating Temperature Range 0°C to 70°C
Storage Temperature Range -40°C to 85°C
Shock Resistance 1500 G / 0.5 ms
Vibration Resistance 20 G (Peak, 20–2000 Hz)
MTBF (Mean Time Between Failures) 2 million hours
Endurance (TBW) 600 TBW

Advanced Security Features
Data Encryption AES 256-bit Encryption
TCG Opal 2.0 Support Yes
Self-Encrypting Drive (SED) Yes
Secure Erase Yes
Drive Sanitization Crypto Erase Supported

Interfaces
Interface Type PCI Express 3.0 x4 (NVMe 1.3)
Interface Connector M-Key Edge Connector
Maximum Sequential Read Speed Up to 3500 MB/s
Maximum Sequential Write Speed Up to 3000 MB/s
Interface Bandwidth 32 Gbps (x4 lanes)

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
RoHS Compliant Yes
Halogen Free Yes
Certifications CE, FCC, BSMI, VCCI

Cloud Management & Licensing
Drive Management Software Supports NVMe SMART Monitoring (via OS tools)
Firmware Upgradable Yes
