Products Memory, Storage and Components Eaton 9PXM UPS, 12-slot, Ra...

Eaton 9PXM UPS, 12-slot, Rack/Tower, 208-240V, 9PXM12BJHHH

VENDOR: EATON Mfg Part#: 9PXM12BJHHH
1 5
Photo is for illustration purposes only. Actual product may be different.
$7,403.00
$7,403.00
Sale Sold out
MSRP: $11,736.00
Shipping calculated at checkout.
  • 12-slot modular design for scalability and customization
  • Rack/Tower form factor for flexible deployment options
  • 208-240V input range supports high-power applications
  • Includes (4) 5-20Rs, (2) L14-30Rs, and (6) L6-30R output receptacles
  • TAA compliant and made in the United States
  • Designed as a UPS for uninterruptible power supply needs

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Tailored for enterprise or government installations with TAA compliance and U.S. origin.
  • Extensive output receptacle variety supports broad IT infrastructure needs in a single device.
  • Modular and scalable design future-proofs power infrastructure without disrupting uptime.

Product Overview

Eaton 9PXM 12 slot, (4) 5-20Rs, (2) L14-30Rs, (6) L6-30R

Specifications

Product Overview
Model Eaton 9PXM
Manufacturer Part Number 9PXM12BJHHH
Type Uninterruptible Power Supply (UPS)
Form Factor Rack/Tower Convertible
Number of Slots 12
Input Voltage Range 208-240V
Nominal Output Voltage 208V
Output Power Capacity 12 kVA
Output Power (Watts) 10800W
Technology Online Double Conversion
Scalability Modular, Scalable up to 20 kVA
Hot-swappable Modules Yes
Redundant Power Module Support Yes
Redundant Battery Module Support Yes
Weight 390 lbs (approximately, fully populated)
Power Requirements 208-240V AC, 50/60 Hz

Physical & Environmental
Rack Height 12U
Dimensions (HxWxD) 20.5 x 17.3 x 28.3 in (520 x 439 x 719 mm)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -15°C to 50°C (5°F to 122°F)
Relative Humidity 0% to 95% non-condensing
Noise Level 48-55 dB depending on load and configuration
Cooling Forced air; fan-cooled

Cloud Management & Licensing
Management Interface LCD front panel, optional network card
Remote Management Yes, with optional network card (SNMP/Web)
Software Included Intelligent Power Manager (optional download)
Network Monitoring Supported via SNMP/Web card

Interfaces
Output Connectors (4) 5-20R, (2) L14-30R, (6) L6-30R
Input Power Connection Hardwired 3-wire (L1, L2, G)
Communication Ports 1 x USB, 1 x Serial (DB-9), 1 x REPO
Network Management Card Slot Yes, Optional
Expansion Slots Multiple battery and power module slots

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications UL 1778, cUL, FCC Class A, RoHS
Environmental Compliance RoHS, REACH

Advanced Security Features
Remote Emergency Power Off (REPO) Supported
Password Protection Yes, via network card
