Extreme 8520-48XT-6C-DC-F 48-Port 10GbE L3 Managed Switch with Front-Back Airflow

VENDOR: EXTREME NETWORK INC Mfg Part#: 8520-48XT-6C-DC-F
1 3
Photo is for illustration purposes only. Actual product may be different.
$35,767.00
$35,767.00
Sale Sold out
MSRP: $51,477.00
Shipping calculated at checkout.
  • 48 x 1/10G copper Ethernet ports and 6 x 100/40G QSFP28 uplinks
  • Switching capacity: 2.16 Tbps, forwarding rate: 1000 Mpps
  • Advanced Layer 3 routing including OSPF, BGP, VRRP, and ECMP
  • Supports 64K MAC address entries and jumbo frames up to 9126 bytes
  • Dual DC power supplies with 1+1 redundancy and front-back airflow
  • 16 GB DDR4 SDRAM with 128 GB SSD and Extreme SLX-OS included

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers exceptional scalability and performance with high-density 10G access and multiple 100G uplinks
  • Enhances network resiliency and uptime through dual power supplies, fan redundancy, and 1+1 power failover
  • Ideal for enterprise and data center deployments with advanced routing, management, and virtualization support

Product Overview

Extreme 8520-48XT Switch with front-back airflow Ships with two DC power supplies six fans one 4-post rack mount kit Supports 48x10/1G copper ports and 6x100/40G fiber ports

Specifications

Product Overview
Type Layer 3 Managed Switch
Form Factor Rack-mountable 1U
Power Requirements DC -48 to -60 V
Power Redundancy Yes
Power Redundancy Scheme 1+1
Power Provided 750 Watt
Included Power Supplies 2 (DC)
Included Fans 6
Included Accessories 4-post rack mount kit
Processor 1
RAM 16 GB DDR4 SDRAM
Built-in Storage 128 GB SSD

Cloud Management & Licensing
Operating System Extreme SLX-OS
Remote Management Protocols SNMP 1/2c/3, RMON 1/2, Telnet, HTTP, HTTPS, SSH, SSH-2, CLI, SCP, NETCONF, RESTCONF, SFTP, NTP, ICMP, DHCP
REST API Support Yes (RESTful APIs)
Zero Touch Provisioning (ZTP) Yes
Cloud-Scale Automation Yes (via RESTCONF/NETCONF/CLI/SCP)

Physical & Environmental
Width 17.3 in
Depth 20.9 in
Height 1.7 in
Minimum Operating Temperature 32 °F (0 °C)
Maximum Operating Temperature 113 °F (45 °C)

Interfaces
RJ-45 Ports (1G/10G) 48 x 1/10Gbit LAN
QSFP28 Ports (40G/100G) 6 x 100Gbit/40Gbit LAN
Console Ports 1 x serial (RJ-45)
Management Ports 1 x 1000Base-T (RJ-45), 1 x USB Type A
MAC Address Table Size 64K entries
Switching Capacity 2.16 Tbps
Forwarding Rate 1000 Mpps
Latency 2.400 ns
Jumbo Frame Support 9126 bytes

Advanced Security Features
Authentication Methods SSH, RADIUS, TACACS+, Active Directory
Encryption Algorithms TLS 1.1, TLS 1.2
Access Control Lists (ACL) Supported (2000 entries)
Port Security Yes
Role-Based Access Control (RBAC) Yes
AAA Support Yes
VLAN Tagging / Filtering IEEE 802.1Q, VLAN support, VLAN encapsulation
BGP GTSM Support Yes
Router Advertisement Guard Yes
BPDU Guard / Filter Yes

Compliance & Origin
Country of Origin Taiwan
TAA Compliance Yes
Compliance Standards IEEE 802.3, 802.3z, 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3x, 802.3ad, 802.1w, 802.1x, 802.3ae, 802.1s, 802.1v, 802.1ab, 802.3ba, 802.3ax
