Extreme 8520-48Y 48-Port 25GbE Leaf Switch, 8x100/40G, AC PSUs, Rack Kit

VENDOR: EXTREME NETWORK INC Mfg Part#: 8520-48Y-8C-AC-R UPC#: 644728053858
1 2
Photo is for illustration purposes only. Actual product may be different.
$32,681.00
$32,681.00
Sale Sold out
MSRP: $47,036.00
Shipping calculated at checkout.
  • 48x 1/10/25GbE SFP28 interfaces and 8x 100/40GbE uplink ports
  • Ships with two 750W AC power supplies and six cooling fans
  • Back-to-front airflow for optimized thermal management
  • 1U rackmount form factor with included 4-post mounting kit
  • 16 GB installed RAM for enhanced processing and buffering
  • Maximum power consumption of 469W for energy efficiency

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for data center and service provider environments requiring high port densities and throughput.
  • TAA-compliant and manufactured in Taiwan, fulfilling government and enterprise procurement standards.
  • Complete hardware package included—power supplies, fans, and rack mount—eases deployment and reduces setup time.

Product Overview

Extreme 8520-48Y Switch with back-front airflow Ships with two AC power supplies six fans one 4-post rack mount kit Supports 48x25/10/1G and 8x100/40G ports

Specifications

Product Overview
Product Type Managed Switch
Model Extreme 8520-48Y
Form Factor 1U
Mounting Type Rack-mountable
Weight 7.58 kg
Power Supply Included 2 x 750W AC PSU (hot-swappable)
Power Consumption (Max) 469 W
Fans Included 6 Hot-swappable Fans
Airflow Direction Back to Front
Switching Capacity 3.6 Tbps
Forwarding Rate 1.6 Bpps

Wireless Features

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
RoHS Compliant Yes
Certifications UL, CE, FCC, VCCI, EN 60950-1
REACH Compliant Yes

Advanced Security Features
Access Control IEEE 802.1X, MAC-based authentication
Switch Security Storm control, DHCP snooping, IP source guard
Network Segmentation Private VLAN, VRF-Lite, ACLs
Secure Management SSH, HTTPS, RADIUS, TACACS+
Authentication RADIUS, TACACS+, LDAP

Interfaces
Primary Uplink Ports 8 x QSFP28 100GbE
Downlink Ports 48 x SFP28 25GbE (supports 1/10/25GbE)
Management Interface 1 x 10/100/1000BASE-T RJ45
Console Ports 1 x RJ-45, 1 x Micro-USB
USB Ports 1 x USB Type-A
Maximum VLANs Supported 4094
MAC Address Table Size 128,000 entries
Jumbo Frames Support Up to 9216 bytes

Physical & Environmental
Dimensions (W x D x H) 17.3 x 21.24 x 1.7 inches
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity (Operating) 5% to 95% non-condensing
Acoustic Noise 65 dB (typical)
Cooling Redundant hot-swappable fans

Cloud Management & Licensing
Management Platform ExtremeCloud IQ
Supported Management Protocols SNMP v1/v2/v3, CLI, Web UI, REST API
License Requirement Requires ExtremeCloud subscription for cloud features
Included Management Options On-box CLI, Zero-touch provisioning, ExtremeXOS/SLX OS support
