Products Network Stuff Extreme 8520-48Y 48-Port 25...

Extreme 8520-48Y 48-Port 25GbE Switch with 8x100GbE Uplinks, DC Power, Front-Back Airflow

VENDOR: EXTREME NETWORK INC Mfg Part#: 8520-48Y-8C-DC-F
1 2
Photo is for illustration purposes only. Actual product may be different.
$36,632.00
$36,632.00
Sale Sold out
MSRP: $52,721.00
Shipping calculated at checkout.
  • 48 SFP28 ports supporting 1/10/25GbE for high-speed access
  • 8 QSFP uplink ports enabling 40/100GbE aggregation
  • 16 GB installed RAM for improved performance and traffic handling
  • Dual 750W DC power supplies and six cooling fans for redundancy
  • Compact 1U form factor with front-to-back airflow for rack optimization
  • TAA compliance and manufactured in Taiwan for regulated environments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports versatile port configurations including 1/10/25/40/100GbE for scalable deployment
  • Front-to-back airflow and multiple integrated fans enhance thermal performance in dense racks
  • TAA compliance and DC power options make it suitable for government and industrial installations

Product Overview

Extreme 8520-48Y Switch with front-back airflow Ships with two DC power supplies six fans one 4-post rack mount kit Supports 48x25/10/1G and 8x100/40G ports

Specifications

Product Overview
Product Type Data Center Leaf Switch
Model 8520-48Y
Form Factor 1U Rack-Mountable
Features Fixed Form Factor Leaf Switches for Service Provider and Data Center
Power Supply Redundancy Dual DC Power Supplies
Power Supply Capacity 750 Watts per PSU
Max Power Consumption 469 Watts
Weight 7.58 kg

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications UL/CSA 60950-1, EN 60950-1, IEC 60950-1, CB Bulletin; FCC Class A, EN55032 Class A, EN55024, EN61000-3-2, EN61000-3-3, ICES-003 Class A
RoHS Compliant Yes
WEEE Compliant Yes
REACH Compliant Yes

Advanced Security Features
Access Control 802.1X Network Access Control
MACsec Support Yes, IEEE 802.1AE
ACLs IPv4/IPv6 Access Control Lists
DHCP Snooping Yes
Dynamic ARP Inspection Yes
IP Source Guard Yes

Interfaces
Total Ports 56
10/25GbE SFP28 Ports 48
40/100GbE QSFP28 Ports 8
Data Transfer Rate Up to 100 Gbps per port
Data Link Protocols Ethernet, Fast Ethernet, Gigabit Ethernet, 10-Gigabit Ethernet, 25-Gigabit Ethernet, 40-Gigabit Ethernet, 100-Gigabit Ethernet
Packet Buffer Size 42 MB
Forwarding Rate Up to 2.16 Bpps
Switching Capacity 4.3 Tbps
MAC Address Table Size Approx. 256,000 entries
Jumbo Frame Support Yes, up to 9216 bytes

Physical & Environmental
Width 17.3 in (439 mm)
Depth 21.24 in (539.5 mm)
Height 1.7 in (43 mm)
Airflow Front-to-Back
Included Cooling 6 Hot-swappable Fans
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 95% (non-condensing)
MTBF >197,000 hours

Cloud Management & Licensing
Management Interface ExtremeCloud IQ, Command Line Interface (CLI), SNMP v1/v2/v3, REST API
Included Management Software ExtremeXOS or Fabric Engine (based on deployment)
Licensing Model Centralized and cloud-based licensing
