EXTREME NETWORK V300HT-8P-2X Fanless PoE+ Switch, 8 GbE, 2 SFP+ Ports

VENDOR: EXTREME NETWORK INC Mfg Part#: V300HT-8P-2X
1 3
Photo is for illustration purposes only. Actual product may be different.
$3,125.00
$3,125.00
Sale Sold out
MSRP: $4,497.00
Shipping calculated at checkout.
  • 8 10/100/1000BASE-T PoE+ ports with half/full duplex support
  • 2x SFP+ ports for high-speed uplinks
  • Fanless design optimized for high-temperature environments
  • Ships with protective front cover for port protection
  • Form factor supports fiber (SFP)
  • Compliant with TAA standards, manufactured in Taiwan

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Fanless and high-temperature-ready design makes it ideal for rugged or space-constrained deployments.
  • TAA compliance supports use in government and regulated agency installations.
  • Includes SFP+ uplink options to extend network range and performance over fiber.

Product Overview

V300HT-8P-2X 8 10/100/1000BASE-T POE+ ports half/full duplex 2xSFP+ ports fanless high temperature model power supply sold separately comes with protective front cover

Specifications

Product Overview
Product Type Managed Layer 2+ Ethernet Switch
Form Factor DIN Rail or Wall Mountable (Fanless)
Weight 1.3 kg (2.87 lbs)
Mounting Type DIN rail or wall mount
Power Supply External power supply, sold separately
Power Consumption 90W maximum (PoE+ full load)
Product Series V300 Series

Physical & Environmental
Dimensions (W x H x D) 200 x 44 x 165 mm (7.87 x 1.73 x 6.5 in)
Operating Temperature -40°C to 75°C (-40°F to 167°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Operating Humidity 5% to 95% non-condensing
Enclosure Type Metal (fanless)
Cooling Passive (Fanless design)
MTBF Over 500,000 hours

Cloud Management & Licensing
Management Interface ExtremeCloud IQ Ready
Management Options Web GUI, Command Line Interface (CLI), SNMP v1/v2c/v3, RMON, sFlow
Included Licensing Base software, subscription for cloud management sold separately
Zero-Touch Provisioning Supported via ExtremeCloud IQ
Configuration Backup & Restore Supported

Interfaces
Ethernet Ports 8 x 10/100/1000BASE-T (PoE+)
SFP+ Ports 2 x 1/10 Gigabit SFP+
PoE Standard IEEE 802.3at (PoE+)
PoE Power Budget 60W
Switching Capacity 56 Gbps
Packet Forwarding Rate 41.7 Mpps
MAC Address Table Size 8K entries
Jumbo Frame Support Up to 9,216 bytes
Auto-MDI/MDIX Supported
Flow Control IEEE 802.3x (full-duplex), back pressure (half-duplex)

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications UL, CE, FCC Class A, VCCI, EN 60950-1, EN 55032, EN 55024
RoHS Compliant Yes
Reach Compliant Yes
Green Compliant Yes

Advanced Security Features
Access Control IEEE 802.1X, MAC-based authentication
Port Security Yes
DHCP Snooping Yes
IP Source Guard Yes
DoS Protection Yes
Storm Control Broadcast, multicast, unknown unicast suppression
