Products Network Stuff Extreme Networks SLX 9540-2...

Extreme Networks SLX 9540-24S DC Switch, 24x10GE/1GE, B2F Airflow

VENDOR: EXTREME NETWORK INC Mfg Part#: BR-SLX-9540-24S-DC-R
1 3
Photo is for illustration purposes only. Actual product may be different.
$54,389.00
$54,389.00
Sale Sold out
MSRP: $78,278.00
Shipping calculated at checkout.
  • Supports 24×10 GbE/1 GbE SFP+ ports and 24×1 GbE ports
  • Designed for back-to-front airflow (non-port to port side)
  • Compliant with IEEE 802.3-2005 networking standards
  • Operates in 0°C to 40°C; stores at -25°C to 55°C
  • Includes 4-post rack mount kit; compact 1.72 inch height
  • DC-powered unit with TAA compliance for regulatory standards

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for high-density data center and service provider environments due to 48 total ports including 24 x 10GE/1GE SFP+.
  • Back-to-front airflow design optimizes thermal efficiency in hot-aisle/cold-aisle deployments.
  • TAA compliance and DC power support make it suitable for federal and enterprise-grade networks.

Product Overview

SLX 9540-24S Switch DC with Back to Front airflow (Non-port Side to port side airflow). Supports 24x10GE/1GE + 24x1GE ports.

Specifications

Product Overview
Manufacturer Extreme Network Inc
Model SLX 9540-24S
Type Layer 3 Fixed Configuration Data Center Switch
Form Factor 1U Rack-mountable
Weight 19.84 lbs.
Power Supply Type Dual hot-swappable DC power supplies
Cooling Direction Back-to-front airflow (B2F)
Rack Mount Kit Included (4-post)
Power Supply Configuration Redundant, hot-swappable

Physical & Environmental
Width 17.32 in
Depth 16.63 in
Height 1.72 in
Min Operating Temperature 0°C
Max Operating Temperature 40°C
Min Storage Temperature -25°C
Max Storage Temperature 55°C
Operating Humidity Range 5% to 95% non-condensing
Acoustic Noise 65 dB (typical)

Cloud Management & Licensing
Management Interface REST API, CLI, SNMPv3, GUI via Extreme Workflow Composer
Included Licensing Base OS license included
Supported Management Extreme Cloud IQ, SLX-OS, SSH, Telnet
Automation Support Ansible, Python scripting, NETCONF/YANG

Interfaces
Total Ports 48
10G/1G SFP+ Ports 24
1G SFP Ports 24
Port Speeds Supported 1 Gbps, 10 Gbps
Port Types SFP, SFP+
Data Transfer Rate 10 Gbps per port
Aggregate Switching Capacity 960 Gbps
Forwarding Rate 720 Mpps
MAC Address Table Size 128K entries
Packet Buffer Memory 16 MB

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
RoHS Compliant Yes
EMI Certifications FCC Part 15 Class A, EN 55032 Class A
Safety Certifications UL 60950-1, CAN/CSA-C22.2 No. 60950-1

Advanced Security Features
Access Control Lists (ACL) Yes
802.1x Authentication Yes
Role-Based Access Yes
Secure Management Interfaces HTTPS, SSH, SNMPv3
