ExtremeSwitching 5420M L3 PoE+ Switch with 58 Ports and MACsec

VENDOR: EXTREME NETWORK INC Mfg Part#: 5420M-16MW-32P-4YE UPC#: 644728051922
1 2
Photo is for illustration purposes only. Actual product may be different.
$13,803.00
$13,803.00
Sale Sold out
MSRP: $19,865.00
Shipping calculated at checkout.
  • 16 x 100M/1G/2.5GBASE-T 802.3bt (90W) PoE ports for high-powered devices
  • 32 x 10/100/1000BASE-T 802.3at (30W) PoE+ ports for standard connectivity
  • 4 x 1/10/25Gb SFP28 uplink ports (unpopulated) for flexible high-speed uplinks
  • MACsec encryption support for Layer 2/3 data security
  • IPv4 and IPv6 remote management capability for interoperability
  • 1RU form factor with two modular power supply slots and included fan module

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports a total of 58 high-speed wired ports including 10/25GbE SFP28 uplinks for scalable performance
  • Delivers up to 90W PoE per port for power-hungry devices, reducing the need for separate power infrastructure
  • Built-in MACsec encryption ensures secure communications in enterprise and sensitive environments

Product Overview

ExtremeSwitching 5420M 16 100Mb/1Gb/2.5Gb 802.3bt 90W PoE 32 10/100/1000BASET FDX/HDX PoE+ 2 stacking/SFP-DD 4 10/25G un-pop SFP28 MACsec capable includes fan module 2 un-pop modular PSU slots.

Specifications

Product Overview
Product Type Layer 3 Managed Switch
Model 5420M-16MW-32P-4YE
Form Factor 1RU
Weight 5.3 Kg
Power Requirements Dual modular PSU slots (unpopulated)
Maximum Power Consumption 2564 Watt
Power Over Ethernet (PoE) Support Yes, PoE+ and 802.3bt (90W) capable
MAC Address Table Size 32000
Switching Capacity
Forwarding Rate

Wireless Features

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Networking Compliant Standards IEEE 802.3ab, 802.3bz, 802.3bt, 802.3ae, 802.3aq, 802.3by, 802.3az
Environmental Standards
Certifications

Advanced Security Features
Encryption Technology MACsec (802.1AE)
Access Control 802.1X port-based authentication
DHCP Snooping Yes
DoS Protection Yes
Storm Control Yes
Port Security Yes
Network Access Control RADIUS, TACACS+

Interfaces
Total Ports 58
Modular Uplink Ports 4 x 1/10/25Gb SFP28 (unpopulated)
Multigigabit Access Ports 16 x 100M/1G/2.5GBASE-T 802.3bt
Standard PoE+ Ports 32 x 10/100/1000BASE-T 802.3at
Stacking Ports 2 x SFP-DD stacking ports (unpopulated)
Console Port 1 x RJ-45 serial console port
Data Transfer Rate Supported Up to 25 Gbps (per uplink)
Data Link Protocols Gigabit Ethernet, Fast Ethernet

Physical & Environmental
Width 17.4 Inch
Depth 13 Inch
Height 1.7 Inch
Minimum Operating Temperature 0 °C
Maximum Operating Temperature 50 °C
Minimum Storage Temperature -40 °C
Maximum Storage Temperature 70 °C
Operating Humidity (Non-Condensing)

Cloud Management & Licensing
Management Interface ExtremeCloud™ IQ optional, CLI, SNMP, Web UI
Cloud-enabled Yes (with ExtremeCloud IQ licensing)
Licenses Included
Remote Management Protocol IPv4
Remote Management Protocol IPv6
Out-of-Band Management Port
