Fortinet FortiAP-231G Indoor Tri-Radio Wi-Fi 6E Access Point

VENDOR: FORTINET Mfg Part#: FAP-231G-S
1 3
Photo is for illustration purposes only. Actual product may be different.
$407.00
$407.00
Sale Sold out
MSRP: $552.00
Shipping calculated at checkout.
  • - Tri-radio access point with Wi-Fi 6E (802.11ax) supporting 2.4GHz, 5GHz, and 6GHz bands
  • - Dual 5G operation with 2+2+2 stream configuration for optimal throughput
  • - One 10/100/1000 Mbps RJ45 port and one 100/1000/2500Base-T multi-gigabit RJ45 port
  • - Integrated internal antennas and included ceiling/wall mount kit for versatile deployment
  • - USB Type-A port and RS-232 RJ45 serial port for enhanced device interfacing
  • - Bluetooth/BLE support for IoT and location services

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Supports Wi-Fi 6E across tri-band frequencies, ensuring next-generation wireless performance for high-density environments.
  • Offers flexible installation and high-speed connectivity with dual Ethernet ports including 2.5GbE and integrated Bluetooth/BLE.
  • Easy deployment with internal antennas, included mounting kits, and multiple powering options (802.3at PoE or AC adapter).

Product Overview

The Fortinet FortiAP-231G is a high-performance indoor tri-radio wireless access point with support for Wi-Fi 6E over 2.4 GHz, 5 GHz, and 6 GHz bands, offering a 2+2+2 stream configuration. It features dual 5G operation and comes with internal antennas for efficient installation. Connectivity includes multi-gig Ethernet (2.5GbE), USB Type-A, and an RS-232 port. Integrated Bluetooth/BLE expands IoT and location-based services capability. Power via 802.3at PoE or an optional AC adapter. Includes mounting kits for ceiling or wall setups—perfect for scalable enterprise wireless solutions.

Specifications

Product Overview
Product Type Indoor Wireless Access Point
Model FortiAP-231G
Wi-Fi Generation Wi-Fi 6E (802.11ax)
Radio Configuration Tri-Radio (2.4 GHz, 5 GHz, 6 GHz)
Spatial Streams 2x2:2 per radio
Combined Data Rate Up to 5.4 Gbps
Antenna Type Internal Antennas
5G Dual Operation Yes
Mounting Options Ceiling and wall mount kits included
Power Options 802.3at PoE or optional external AC adapter
Weight 0.89 kg (1.96 lbs)
Power Consumption Up to 22.6 W

Wireless Features
Wi-Fi Standards 802.11a/b/g/n/ac/ax (Wi-Fi 6/6E)
Frequency Bands 2.4 GHz, 5 GHz, 6 GHz
MIMO Configuration 2x2 per band
Max Clients per Radio Up to 512 total (depending on configuration)
MU-MIMO Yes, DL/UL MU-MIMO supported
OFDMA Support Yes
Band Steering Supported
Beamforming Supported (implicit and explicit)

Compliance & Origin
Country of Origin Taiwan
Certifications FCC, CE, IC, UKCA, CB, UL, Wi-Fi 6E Alliance Certified
RoHS Compliance Yes

Advanced Security Features
WIDS/WIPS Yes
Rogue AP Detection Yes
Application Control Yes, when integrated with FortiGate
Firewall Integration Yes, via FortiGate UTM features
VPN Tunneling Supported (VPN over CAPWAP)

Interfaces
Ethernet Port 1x 2.5 Gbps RJ45 Ethernet (PoE-In)
USB Port 1x USB 2.0 Type-A
Console Port 1x RJ45 Serial (RS-232)
Bluetooth/BLE Integrated BLE 5.0
Mounting Interface Standard Fortinet bracket

Physical & Environmental
Dimensions 220 × 220 × 45 mm (8.66 × 8.66 × 1.77 in)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 10% to 90% (non-condensing)
Storage Humidity 5% to 90% (non-condensing)
Enclosure Rating Plastic indoor enclosure

Cloud Management & Licensing
Controller Options FortiGate, FortiLAN Cloud, FortiWLM
Cloud Management Supported via FortiLAN Cloud
Licensing Model License-free when managed via FortiGate
