Fortinet FortiAP-432G Outdoor Wireless Access Point, Tri-Radio

VENDOR: FORTINET Mfg Part#: FAP-432G-Y
1 3
Photo is for illustration purposes only. Actual product may be different.
$2,675.00
$2,675.00
Sale Sold out
MSRP: $3,655.00
Shipping calculated at checkout.
  • - Tri-radio design: supports one 4x4 802.11b/g/n/ax, one 4x4 802.11a/n/ac/ax, and one 2x2 802.11a/b/g/n/ac/ax 6GHz radio
  • - Outdoor-rated build for enterprise-grade deployment in harsh environments
  • - Supports Wi-Fi 6E (6GHz) for future-ready wireless networking
  • - Integrated with Fortinet security and management ecosystem
  • - Manufactured in Taiwan, indicating quality production standards

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Expanded tri-radio support offers high-capacity, multi-band connectivity for complex networks.
  • Wi-Fi 6E compatibility enables access to the 6GHz band, boosting bandwidth and reducing latency.
  • Outdoor-ready construction makes it ideal for demanding enterprise and industrial environments.

Product Overview

The Fortinet FortiAP-432G is a rugged and powerful outdoor wireless access point equipped to meet modern enterprise connectivity requirements. Featuring tri-radio capabilities, it combines one 4x4 802.11b/g/n/ax radio, one 4x4 802.11a/n/ac/ax radio, and one 2x2 802.11a/b/g/n/ac/ax 6GHz radio. This setup enables simultaneous high-speed connections across multiple bands, enhancing wireless performance. It's ideal for high-density outdoor deployments. As part of Fortinet’s secure ecosystem, the FortiAP-432G ensures seamless integration with FortiGate firewalls and centralized management. The 6GHz band allows for additional bandwidth and reduced interference, though its availability depends on regulatory domains. Manufactured in Taiwan, this unit offers a balance of security, performance, and outdoor resilience for enterprise environments.

Specifications

Product Overview
Product Type Outdoor Wireless Access Point
Model FortiAP-432G
Form Factor Outdoor, IP67-rated enclosure
Wireless Radios Tri-Radio (2x 4x4 MIMO + 1x 2x2 MIMO)
Power Consumption 25.8W max
Power Input 802.3at PoE+ (Power over Ethernet)
Mounting Options Pole and wall mountable
Weight 2.5 kg (5.51 lbs)

Wireless Features
Wi-Fi Standards 802.11a/b/g/n/ac/ax, including 6 GHz (Wi-Fi 6E)
Radio Bands 2.4 GHz, 5 GHz, 6 GHz
MIMO Configuration 4x4 MU-MIMO for 2.4 GHz and 5 GHz, 2x2 MU-MIMO for 6 GHz
Maximum Data Rate (2.4 GHz) Up to 1.147 Gbps
Maximum Data Rate (5 GHz) Up to 4.8 Gbps
Maximum Data Rate (6 GHz) Up to 2.4 Gbps
Antenna Type Integrated omnidirectional antennas
Antenna Gain 4 dBi for 2.4/5 GHz, 5 dBi for 6 GHz

Compliance & Origin
Country of Origin Taiwan
Certifications FCC, CE, IC, UL, CB, Wi-Fi 6E Certified
RoHS Compliant Yes

Advanced Security Features
WIDS/WIPS Yes, Wireless Intrusion Detection and Prevention System
Client Device Identification Yes
Application Control Yes, when integrated with FortiGate
Content Filtering Supported via FortiGate integration
VPN Tunnel Support IPSec tunnels to FortiGate

Interfaces
Ethernet Ports 2 x 1G/2.5G Ethernet Ports (RJ-45)
SFP Ports 1 x 1G/2.5G SFP Port
Management Interface 1 x Console Port (RJ-45)
PoE Input 802.3at Power over Ethernet (PoE+) via Ethernet port
Data Transfer Rate Up to 10.2 Gbps aggregate throughput

Physical & Environmental
Dimensions 31.3 x 24.1 x 9.6 cm (12.3 x 9.5 x 3.8 in)
Enclosure Rating IP67 (Outdoor weatherproof)
Mounting Kit Included Yes
Operating Temperature -40°C to +65°C (-40°F to +149°F)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Operating Humidity 5% to 95% non-condensing

Cloud Management & Licensing
Management Platform FortiGate, FortiCloud, FortiLAN Cloud
Zero Touch Deployment Supported via FortiCloud
License Requirement No license required for FortiGate management; license needed for FortiCloud Advanced Features
Included Management Option FortiLAN Cloud (Basic tier included)
