Fortinet FortiWiFi-40F-3G4G with 3YR FortiCare & FortiGuard Enterprise

VENDOR: FORTINET Mfg Part#: FWF-40F-3G4G-Y-BDL-809-36
1 3
Photo is for illustration purposes only. Actual product may be different.
$3,578.00
$3,578.00
Sale Sold out
MSRP: $4,885.00
Shipping calculated at checkout.
  • Supports LTE/3G/4G cellular connectivity with SMA antenna connectors
  • Wireless dual-band (2.4 GHz and 5 GHz) operation with 3x3 MIMO
  • Up to 1 Gbps IPS throughput and 4.4 Gbps IPsec VPN throughput
  • Handles up to 700,000 concurrent sessions and 35,000 new sessions per second
  • Includes 7 Ethernet ports and uses Gigabit Ethernet protocols
  • Low power usage with max power consumption of 19.8 watts

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • All-in-one bundle includes 3-year FortiCare Premium and FortiGuard Enterprise Protection, reducing total cost of ownership
  • Excellent performance with high session handling and throughput for remote offices and SMBs
  • Compact desktop form factor with robust wireless and cellular networking capabilities for flexible deployment

Product Overview

The Fortinet FortiWiFi-40F-3G4G is a versatile network security appliance designed for distributed enterprises, remote sites, and mobile deployments. With support for LTE and 3G/4G connectivity via SMA connectors and 3x3 MIMO antennas, this unit ensures reliable and secure internet access even in challenging network environments. Its desktop form factor makes it well-suited for constrained spaces, while the integrated wireless module supports dual-band frequency operation at 2.4 GHz and 5 GHz for reduced interference and improved client performance.

Equipped with seven networking ports and Gigabit Ethernet transport protocols, the FortiWiFi-40F-3G4G offers seamless wired and wireless connectivity. Performance highlights include 1 Gbps IPS throughput, 4.4 Gbps IPsec VPN support, and a capacity for up to 700,000 concurrent sessions, making it an appropriate solution for small organizations with demanding traffic volumes. Its maximum power consumption is just 19.8 watts, further improving deployment value in energy-conscious environments.

This bundle includes a 3-year subscription to FortiCare Premium support and FortiGuard Enterprise Protection, providing proactive security updates, expert assistance, and threat intelligence. This all-in-one security and connectivity solution helps reduce complexity while maintaining high protection standards, making it a strong fit for growing businesses requiring robust edge security.

Specifications

Product Overview
Product Type Network Device
Model FORTIWIFI-40F-3G4G
Manufacturer Part Number FWF-40F-3G4G-Y-BDL-809-36
Form Factor Desktop
Weight 1.87 lbs (0.85 kg)
Max Power Consumption 19.8 Watt
Power / Voltage Required 100-240V
Service & Support Type 3 YEAR HARDWARE PLUS FORTICARE PREMIUM AND FORTIGUARD ENTERPRISE PROTECTION

Wireless Features
Connectivity Technology Wireless
Frequency Band 2.4 GHz; 5 GHz
Wireless Standards 802.11a/b/g/n/ac
Radio Count Single
MIMO Type 3x3 MIMO
Antenna Connectors SMA
Cellular Technology LTE
Cellular Generation 3G
Cellular Generation 4G
SIM Card Slots 1 x Micro SIM slot
LTE Bands Supported B1, B2, B3, B4, B5, B7, B8, B13, B20, B25, B26, B28
3G Bands Supported B1, B2, B5, B8

Compliance & Origin
Country of Origin
TAA Compliance
Certifications FCC, CE, IC, RCM, UL/cUL, CB

Advanced Security Features
Firewall Type Next-Generation Firewall (NGFW)
IPS/IDS Intrusion Prevention System Included
Antivirus Included with FortiGuard Subscription
Web Filtering Included with FortiGuard Subscription
Application Control Yes
Malware Protection Yes, with FortiGuard
SSL Inspection Yes, including Deep SSL Inspection

Interfaces
Networking Type Ethernet
Data Link Protocol Gigabit Ethernet
Transport Protocol Gigabit Ethernet
Networking / Ports Qty 7
WAN Ports 1 x GE RJ45
LAN Ports 5 x GE RJ45
DMZ Port 1 x GE RJ45
USB Ports 1 x USB (for Modem/Storage)
Console Port 1 x RJ45
Throughput - Firewall 5 Gbps
Throughput - Threat Protection 600 Mbps
Concurrent Sessions 700000
New Sessions Per Second 35000
VPN IPSec Throughput 4.4 Gbps
IPS Throughput 1 Gbps

Physical & Environmental
Width 8.5 Inch
Depth 6.3 Inch
Height 1.6 Inch
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature -31°F to 158°F (-35°C to 70°C)
Operating Humidity 10% to 90% non-condensing
Storage Humidity 5% to 95% non-condensing

Cloud Management & Licensing
Management Interface FortiOS via Web, CLI, and FortiCloud
Included Licenses 3-Year FortiCare Premium & FortiGuard Enterprise Protection
Cloud Services FortiCloud Centralized Management & Logging
