Fortinet FortiWiFi-80F-2R-3G4G-DSL + 3YR FortiCare & FortiGuard Bundle

VENDOR: FORTINET Mfg Part#: FWF-80F-2R-3G4G-DSL-D-BDL-809-36
1 3
Photo is for illustration purposes only. Actual product may be different.
$11,743.00
$11,743.00
Sale Sold out
MSRP: $16,039.00
Shipping calculated at checkout.
  • Dual radio Wi-Fi with 2.4 GHz and 5 GHz frequency support (3x3 MIMO)
  • Built-in LTE/3G/4G cellular connectivity with SMA antenna connectors
  • Supports up to 700,000 concurrent sessions and 35,000 new sessions per second
  • High-performance IPSec VPN throughput of 4.4 Gbps
  • Includes 15 Gigabit Ethernet ports for versatile networking
  • Integrated 3-year FortiCare Premium and FortiGuard Enterprise Protection

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Combines firewall, Wi-Fi, and LTE in a single appliance to streamline infrastructure and reduce capital costs
  • Enterprise-grade performance with 4.4 Gbps VPN throughput and high concurrent session capacity ensures reliable connectivity under load
  • Includes 3-year FortiCare and FortiGuard services offering updates, global threat intelligence, and expert support

Product Overview

The Fortinet FortiWiFi-80F-2R-3G4G-DSL is a desktop security appliance designed for enterprise-grade connectivity and protection. It features dual-band Wi-Fi, LTE/3G/4G support, and handles 700,000 concurrent sessions for demanding networks. With a throughput of 4.4 Gbps VPN and 15 Ethernet ports, it serves branch offices and SMBs efficiently. The includes 3-year FortiCare Premium and FortiGuard Enterprise Protection ensures robust support, updates, and threat intelligence, maximizing network reliability and reducing security risk.

Specifications

Product Overview
Product Type Network Device
Form Factor Desktop
Model FORTIWIFI-80F-2R-3G4G-DSL
Networking Type Ethernet
Max Power Consumption 34.31 Watt
Power / Voltage Required 100-240V
Weight 1.9 kg
Processor SoC4 dual-core ARM Cortex-A9
Flash Memory 16 GB
System Memory 4 GB DDR4

Wireless Features
Connectivity Technology Wireless
Data Link Protocol Wi-Fi
Frequency Band 2.4 GHz; 5 GHz
Radio Count Dual
Wi-Fi Standards 802.11a/b/g/n/ac
Antenna Type Antenna
MIMO Type 3x3 MIMO
Antenna Connectors SMA
Cellular Technology LTE
Cellular Generation 3G
Cellular Generation 4G
SIM Slots 1 x Nano-SIM
LTE Bands Supported Bands 1, 3, 5, 7, 8, 20, 28, 38, 40

Compliance & Origin
Country of Origin Inquire
TAA Compliance Inquire
Certifications FCC, IC, CE, RCM, UL/cUL, CB
Environmental Standards RoHS, WEEE

Advanced Security Features
Firewall Throughput 10 Gbps
VPN IPSec Throughput 4.4 Gbps
Concurrent Sessions 700000
New Sessions Per Second 35000
IPS Throughput 1 Gbps
Threat Protection Throughput 700 Mbps
SSL VPN Throughput 900 Mbps
NGFW Throughput 1 Gbps
Content Filtering Included via FortiGuard
Anti-Malware Included via FortiGuard
Web Filtering Included via FortiGuard
Intrusion Prevention System (IPS) Included via FortiGuard

Interfaces
Data Link Protocol Gigabit Ethernet
Transport Protocol Gigabit Ethernet
Networking / Ports Qty 15
10/100/1000 LAN Ports 8
WAN Ports 2
SFP Ports 2
RJ45 Serial Console Port 1
USB Ports 1 x USB 3.0 Type-A

Physical & Environmental
Width 8.5 Inch
Depth 7 Inch
Height 2.4 Inch
Operating Temperature 0°C to 40°C
Storage Temperature -40°C to 70°C
Operating Humidity 10% - 90% non-condensing
Acoustic Noise Level Fanless (Silent Operation)
Cooling Type Passive

Cloud Management & Licensing
Management Interface FortiOS Web UI, CLI, FortiCloud
Licensing 3-Year FortiCare Premium and FortiGuard Enterprise Protection
Included Cloud Features Cloud-based Threat Intelligence, Centralized Management
Subscription Type Bundle (Hardware + 3-Year License)
