Products Network Stuff Fortinet FortiWiFi-81F-2R 3...

Fortinet FortiWiFi-81F-2R 3G4G DSL w/ 5YR FortiCare & FortiGuard

VENDOR: FORTINET Mfg Part#: FWF-81F-2R-3G4G-DSL-D-BDL-809-60
1 3
Photo is for illustration purposes only. Actual product may be different.
$17,569.00
$17,569.00
Sale Sold out
MSRP: $24,001.00
Shipping calculated at checkout.
  • Desktop security appliance with 15 networking ports
  • Dual-band 2.4 GHz and 5 GHz wireless connectivity
  • 3G/4G LTE cellular support with SMA antenna connectors
  • Up to 700,000 concurrent sessions and 35,000 new sessions/sec
  • IPS throughput of 1 Gbps for high-performance threat detection
  • Includes 128 GB internal storage and consumes max 35.6W

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Includes 5-Year FortiCare Premium and FortiGuard Enterprise Protection for full security coverage and support
  • Combines Ethernet, Wi-Fi, and LTE connectivity in one compact device, maximizing deployment flexibility
  • Supports high session and throughput capacities, suited for advanced branch security needs

Product Overview

The Fortinet FortiWiFi-81F-2R-3G4G-DSL is a desktop security appliance offering dual-band wireless (2.4 GHz and 5 GHz), Gigabit Ethernet, and 3G/4G LTE cellular backup. Designed for distributed enterprises and small offices, it boasts 700,000 concurrent sessions capacity and 1 Gbps IPS throughput. With 15 networking ports and 128 GB internal storage, it supports high-data traffic and secure operations. The bundle includes 5-Year FortiCare Premium and FortiGuard Enterprise Protection, providing ongoing support and threat intelligence.

Specifications

Product Overview
Product Type Security Appliance
Model FWF-81F-2R-3G4G-DSL
Form Factor Desktop
Weight 1.47 kg
Power Requirements 100–240V AC, 50–60 Hz
Max Power Consumption 35.6 Watt
Hard Drive 128 GB SSD
Concurrent Sessions 700000
New Sessions Per Second 35000
IPS Throughput 1 Gbps

Wireless Features
Radio Count Dual
Frequency Band 2.4 GHz; 5 GHz
Wi-Fi Standards 802.11a/b/g/n/ac (Wave 2)
Antenna Type External Antennas (Removable)
Wireless Modes Access Point, Bridge, Client
MIMO 2x2 MIMO

Compliance & Origin
Country of Origin Inquire
TAA Compliance Inquire
Certifications FCC, CE, ICES, VCCI, RCM, UL/cUL
RoHS Compliance Yes

Advanced Security Features
Firewall Throughput 1.4 Gbps
VPN Throughput 750 Mbps (IPSec)
SSL Inspection Throughput 160 Mbps
Application Control Yes
Web Filtering Yes
Antivirus Yes
Intrusion Prevention System (IPS) Yes
Anti-Spam Yes
Malware Protection Yes
Advanced Threat Protection Yes (with FortiSandbox integration)
Cloud Sandboxing Supported
SSL VPN Support Yes
IPSec VPN Support Yes

Interfaces
Networking / Ports Qty 15
Interface Types 1x GE RJ45 WAN, 12x GE RJ45 Switch Ports, 2x GE RJ45 DMZ/HA Ports
Management Port Yes (dedicated GE RJ45 port)
Console Port 1x RJ45 Serial
USB Interfaces 1x USB 2.0
Cellular Interface Embedded LTE Modem with 2x SMA Connectors
Antenna Connectors SMA
Data Link Protocol Gigabit Ethernet
Transport Protocol Gigabit Ethernet

Physical & Environmental
Width 8.5 Inch
Depth 7 Inch
Height 2.4 Inch
Operating Temperature 0° to 40°C (32° to 104°F)
Storage Temperature -35° to 70°C (-31° to 158°F)
Operating Humidity 10% to 90% non-condensing
Noise Level Fanless, Silent Operation

Cloud Management & Licensing
Management Interface FortiOS, Web GUI, CLI, FortiCloud
Cloud Management Supported via FortiCloud
Management Protocols HTTPS, SSH, SNMP, Syslog
Included Licensing 5-Year FortiCare Premium and FortiGuard Enterprise Protection
