GIGABYTE B550M K Micro ATX AMD B550 Motherboard, Socket AM4, DDR4, 128GB

VENDOR: GIGABYTE Mfg Part#: B550M K UPC#: 889523036006
1 3
Photo is for illustration purposes only. Actual product may be different.
$135.00
$135.00
Sale Sold out
MSRP: $141.00
Shipping calculated at checkout.
  • Supports AMD Ryzen 5000, 4000 G-Series, and 3000 Series Processors
  • Micro ATX form factor with AMD B550 chipset
  • Supports up to 128GB DDR4 memory with ECC and Non-ECC
  • Integrated DisplayPort and HDMI outputs
  • Includes PCI Express x16 slot and various USB/audio/RJ-45 interfaces
  • Legacy support with PS/2 keyboard/mouse port

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Broad processor compatibility allows use with multiple generations of Ryzen CPUs for upgrade flexibility.
  • High memory capacity with ECC support ensures dependable system performance for multitasking and professional use.
  • Compact Micro ATX form factor with full connectivity makes it ideal for building efficient desktop systems in space-limited setups.

Product Overview

The GIGABYTE B550M K motherboard brings performance, stability, and upgradeability to compact computing setups. Built on the AMD B550 chipset and supporting Socket AM4, it is compatible with a wide range of AMD Ryzen processors, including the 5000, 4000 G-Series, and 3000 lines. The board supports up to 128GB of DDR4 memory with both ECC and non-ECC types. This Micro ATX form factor board fits in smaller enclosures, offering flexibility for users seeking compact but powerful configurations.

Equipped with essential connection and expansion options, the B550M K features DisplayPort and HDMI video outputs, a full suite of USB and audio interfaces, and Ethernet networking via RJ-45. The PCI Express x16 slot ensures compatibility with current-generation GPUs or expansion cards, adapting it well for diverse applications, from home office to light gaming or workstation use. The board also includes legacy PS/2 support. With its balanced features and compact design, the B550M K delivers strong value for mainstream PC builders.

Specifications

Product Overview
Product Type Motherboard
Form Factor Micro ATX
Chipset AMD B550
Processor Socket Socket AM4
Supported Processors AMD Ryzen 5000 Series, Ryzen 5000 G-Series, Ryzen 4000 G-Series, Ryzen 3000 Series, Ryzen 3000 G-Series
Maximum Memory Supported 128 GB
Memory Type DDR4
ECC Support Yes (ECC and non-ECC supported)
Power Requirements 24-pin ATX main power connector and 8-pin ATX 12V power connector
Audio Realtek ALC887 audio codec; High Definition Audio; 2/4/5.1/7.1-channel
CPU Power Phases 5+3 Phases Digital VRM Solution

Wireless Features
Wi-Fi

Compliance & Origin
Country of Origin China
Certifications CE, FCC, BSMI
RoHS Compliance Yes

Advanced Security Features
TPM Support Firmware TPM (fTPM) supported with AMD Ryzen processors
Secure Boot Yes
BIOS Password Protection Yes

Interfaces
PCIe x16 Slots 1 x PCI Express 4.0/3.0 x16 slot (depending on processor)
PCIe x1 Slots 2 x PCI Express x1 slots
Video Output 1 x HDMI, 1 x DisplayPort
USB Ports (Rear) 4 x USB 3.2 Gen 1 Type-A, 2 x USB 2.0
USB Ports (Internal) 2 x USB 2.0 headers, 1 x USB 3.2 Gen 1 header
Audio Jacks 3 x 3.5mm audio jacks (Line-in, Line-out, Mic-in)
LAN Ports 1 x RJ-45
PS/2 Ports 1 (combo port for keyboard/mouse)
Internal Storage Interfaces 4 x SATA 6Gb/s ports, 1 x M.2 connector (PCIe 4.0 x4 or PCIe 3.0 x4/SATA)
LAN Controller Realtek GbE LAN

Physical & Environmental
Motherboard Dimensions (W x D) 24.4 cm x 24.4 cm
Operating Temperature 0°C to 85°C (non-condensing)
Operating Humidity 10% to 90% RH (non-condensing)

Cloud Management & Licensing
Remote Management
Bundled Software GIGABYTE APP Center, BIOS, @BIOS, EasyTune, System Information Viewer
BIOS Type AMI UEFI BIOS
BIOS Features PnP, DMI, WfM, SM BIOS, ACPI, Q-Flash
Firmware Update Method Q-Flash (via UEFI BIOS)
