HighPoint RR620L PCIe 2.0 x4 2-Channel SATA 6Gb/s RAID Controller

VENDOR: HIGHPOINT TECHNOLOGIES, INC. Mfg Part#: RR620L UPC#: 643653620807
1 4
Photo is for illustration purposes only. Actual product may be different.
$69.00
$69.00
Sale Sold out
Shipping calculated at checkout.
  • - PCIe 2.0 x4 interface for high-speed bandwidth
  • - 2-channel 6Gb/s SATA connectivity for fast data transfer
  • - Supports RAID 0, 1, JBOD, and non-RAID configurations
  • - Compatible with Windows, Linux, and macOS operating systems
  • - Includes WebGUI, CLI, BIOS, and UEFI RAID management options

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • - Flexible RAID configurations (RAID 0, 1, JBOD) offer performance and redundancy for various use cases
  • - Cross-platform support ensures compatibility across Windows, Linux, and macOS environments
  • - Comprehensive management interfaces enhance ease of deployment and streamlining of RAID setup

Product Overview

The HighPoint RR620L RAID controller is designed to deliver efficient storage performance for workstations and professional computing setups. Featuring a PCIe 2.0 x4 interface, it provides high-speed bandwidth to support two SATA 6Gb/s channels. This controller supports a range of RAID configurations including RAID 0, RAID 1, JBOD, and non-RAID modes, allowing users to choose between performance, redundancy, or flexibility based on their workflow requirements. Its compatibility with Windows, Linux, and macOS ensures deployment across a range of platforms and systems.

Designed with IT professionals and system builders in mind, the HighPoint RR620L includes versatile management tools. These range from user-friendly WebGUI interfaces to command-line control via CLI, as well as BIOS and UEFI-level accessibility for pre-boot configuration. Suited for users dealing with digital media management, backups, or business-critical data applications, this controller offers a cost-effective way to improve system storage without overhauling existing infrastructure. Manufactured in China and not TAA compliant, the RR620L is particularly well-suited for non-government or international applications.

Specifications

Product Overview
Product Type RAID Controller
Form Factor Low-profile PCIe card
RAID Levels Supported RAID 0, RAID 1, JBOD, Non-RAID
Power Requirements Typical: <10W (via PCIe slot)
Included Accessories Low-profile bracket, Quick Installation Guide
Supported Operating Systems Windows, macOS, Linux

Cloud Management & Licensing
Management Interface WebGUI, CLI, BIOS/UEFI
OS Level Management Tools HighPoint Web RAID Management (HRM)
Pre-Boot Configuration Yes, via BIOS/UEFI utility
Driver Support Windows 10/11, Linux Kernel 3.x and later, macOS (select versions)
Licensing No additional licensing required

Physical & Environmental
Card Dimensions 5.71 x 2.71 in. (145 x 69 mm)
Card Height Low-Profile (with bracket)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 60% non-condensing
Cooling Passive heat sink

Interfaces
Host Interface PCI Express 2.0 x4
Device Interface SATA 6 Gb/s
Number of SATA Ports 2 internal ports
Data Transfer Rate Up to 6 Gb/s per port
Port Type Standard SATA
Interface Compatibility Backward compatible with SATA 3Gb/s and 1.5Gb/s

Compliance & Origin
Country of Origin China
TAA Compliant No
RoHS Compliant Yes
Certifications CE, FCC, RoHS

Advanced Security Features
Bootable RAID Support Yes
UEFI Boot Support Yes
Drive Encryption No native support
Hot Swap Support Operating system dependent
Error Handling Automatic RAID rebuild upon drive replacement
SMART Monitoring Yes, through management utility
