HP Aruba 8360-12C Switch, 12-Port 40GbE, 16GB/32GB, JL709A#ARB

VENDOR: HP Mfg Part#: JL709A#ARB UPC#: 190017405940
1 4
Photo is for illustration purposes only. Actual product may be different.
$39,796.00
$39,796.00
Sale Sold out
MSRP: $50,267.00
Shipping calculated at checkout.
  • 12 ports of 40 Gigabit Ethernet for high-speed connectivity
  • Supports 16GB memory, expandable up to 32GB
  • Wired switching throughput of 40Gbps
  • TAA compliant for government and regulatory environments
  • Made in Singapore, providing origin traceability

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for enterprise environments needing high-speed switching with 40Gbps performance.
  • TAA compliance makes it a fit for public sector and government procurement.
  • Memory expandability up to 32GB allows for extended network scaling and advanced configuration.

Product Overview

The HP Aruba 8360-12C is a powerful Layer 2/3 Ethernet switch optimized for high-bandwidth applications and scalable enterprise networks. With a switching capacity of 40Gbps and 12 dedicated 40 Gigabit Ethernet ports, it is tailored for data centers, hosting environments, and high-demand networking infrastructures. The unit supports flexible memory configurations with 16GB onboard and up to 32GB.

Designed and made in Singapore, the switch complies with TAA requirements, making it suitable for government and other regulated-sector deployments. While detailed performance metrics are not provided, the Aruba 8360 series is positioned as a robust solution for organizations requiring fast, secure, and scalable networking hardware. Its compact port count with high-throughput capacity makes it a strong candidate for edge deployments in data centers, enabling fast uplink or top-of-rack integration.

Specifications

Product Overview
Product Type Layer 2/3 Managed Ethernet Switch
Model HP Aruba 8360-12C
Form Factor 1U Rack-mountable
Weight 7.03 lb (3.19 kg)
Power Supply Dual redundant hot-swappable power supplies supported
Power Consumption (Typical) 130 W
Switching Capacity 960 Gbps
Forwarding Rate 714.28 Mpps
Onboard Memory 16 GB
Maximum Memory Supported 32 GB

Wireless Features
Wireless Connectivity

Compliance & Origin
Country of Origin Singapore
TAA Compliant Yes
Certifications UL, CSA, CB, EN 60950, RoHS, WEEE, REACH
Environmental Compliance ROHS, REACH

Advanced Security Features
Access Control 802.1X Authentication, MAC authentication, Web authentication
Traffic Filtering ACLs (Access Control Lists)
Encryption SSH, SNMPv3, HTTPS
Security Compliance FIPS 140-2 (optional module required)
Storm Control Yes

Interfaces
Ethernet Ports 12 x 40G QSFP+
Management Ports 1 x RJ45 serial console, 1 x RJ45 out-of-band management, 1 x USB Type-A
Uplink Speed 40 Gbps per port
Port Type QSFP+ (Supports 40G only, no breakout)
Packet Buffer Size 64 MB
MAC Address Table Size 128K entries
Latency <1 μs

Physical & Environmental
Dimensions (W x D x H) 43.46 x 51.54 x 4.39 cm (17.11 x 20.29 x 1.73 in)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Operating Humidity 5% to 95% non-condensing
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Acoustic Noise 55 dB (typical)
Cooling Front-to-back or back-to-front airflow options
Mounting Options Rack-mount kit included

Cloud Management & Licensing
Management Interface Aruba NetEdit, Web GUI, CLI, REST API, Aruba Central (cloud-managed optional)
Licensing Model ArubaOS-CX software included; additional features via subscriptions
Cloud-Compatible Yes, with Aruba Central
