HP t540 Thin Client, AMD R1305G, 8GB RAM, 64GB Flash, Win10 IoT, Black

VENDOR: HP Mfg Part#: 7E3D1UT#ABA UPC#: 197192163924
1 3
Photo is for illustration purposes only. Actual product may be different.
$682.00
$682.00
Sale Sold out
MSRP: $744.00
Shipping calculated at checkout.
  • AMD Ryzen Embedded R1305G 1.5 GHz processor with 4MB L3 cache
  • 8GB DDR4 RAM, 2400 MHz; expandable to 16GB
  • 64GB flash storage; supports up to 512GB
  • Integrated AMD Radeon Vega graphics
  • Multiple USB ports (USB 3.0, Type-C), dual DisplayPort 1.2
  • Built-in security features: AMD Memory Guard, UEFI Secure Boot, TPM

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for secure enterprise deployments with TPM, UEFI Secure Boot, and AMD Memory Guard
  • Energy Star and EPEAT Silver certified—good for green IT initiatives
  • Comes with a 3-year limited warranty for long-term support and lower TCO

Product Overview

The HP t540 Thin Client is engineered for secure, high-efficiency computing in enterprise or remote work settings. Powered by an AMD Ryzen Embedded R1305G processor with a base clock of 1.5 GHz and 4MB L3 cache, it delivers commercial-class performance while maintaining exceptional power efficiency. It includes 8GB of DDR4 memory operating at 2400 MHz, and 64GB of expandable flash storage (up to 512GB supported), ensuring responsive application performance and ample data handling capacity.

Built to operate within secure IT frameworks, the t540 includes enterprise-grade safety mechanisms such as AMD Memory Guard, UEFI Secure Boot, and a certified Trusted Platform Module (TPM) for added data protection. Its design features multiple high-speed USB ports—including Type-C—dual DisplayPort 1.2 outputs, and integrated wired Ethernet connectivity. The integrated Radeon Vega graphics and internal amplified speaker system offer essential multimedia support. With Energy Star certification, EPEAT Silver registration, and TAA compliance, it supports both environmental sustainability and government deployment standards.

Designed for easy deployment, minimal maintenance, and robust lifecycle management, the HP t540 is suitable for use in call centers, healthcare, education, and enterprise virtualization environments. Its compact chassis and 3-year limited warranty support long-term return on investment.

Specifications

Product Overview
Product Type Thin Client
Model HP t540
Form Factor Thin Client
Processor AMD Ryzen Embedded R1305G
Processor Clock Speed 1.5 GHz
Processor Core Count 2 (2 cores / 4 threads)
L3 Cache Size 4 MB
Memory Type DDR4 SDRAM
Memory Installed 8 GB
Maximum Memory Supported 16 GB
Memory Speed 2400 MHz
Flash Storage Capacity 64 GB
Maximum Flash Storage 512 GB
Operating System Microsoft Windows 10 IoT Enterprise
Graphics Processor AMD Radeon Vega
Audio Output Integrated amplified speaker system
Standard Warranty 3-year limited warranty
Power Supply Type External Power Adapter
Color Black

Wireless Features
Wireless LAN

Compliance & Origin
Country of Origin Mexico
EPEAT Level Silver
Energy Star Certified Yes
TAA Compliant Yes

Advanced Security Features
Secure Boot UEFI Secure Boot
Trusted Platform Module (TPM) Included, certified TPM 2.0
Memory Encryption AMD Memory Guard
Physical Security Cable lock slot

Interfaces
USB 2.0 Ports 2 x Type-A (rear)
USB 3.2 Gen 1 Ports 3 x Type-A (2 rear, 1 front)
USB Type-C Ports 1 x USB Type-C 3.2 Gen 1 (front)
DisplayPort Outputs 2 x DisplayPort 1.2 (rear)
Audio Ports 1 x 3.5mm combo headphone/mic jack (front)
Ethernet Port 1 x RJ-45 (Gigabit Ethernet)

Physical & Environmental
Width 1.38 in (35 mm)
Depth 7.87 in (200 mm)
Height 7.87 in (200 mm)
Weight 1.03 kg (2.28 lbs)
Operating Temperature Range 50°F to 104°F (10°C to 40°C)
Operating Humidity Range 10% to 90% (non-condensing)
Non-Operating Humidity 5% to 95% (non-condensing)

Cloud Management & Licensing
Management Interface HP Device Manager, HP Write Manager
Licensing Windows 10 IoT Enterprise license included
