HP Z6 G5 Workstation Xeon W5-3423 16GB 512GB SSD NVIDIA T400

VENDOR: HP Mfg Part#: 81N37UT#ABA UPC#: 197497248852
1 3
Photo is for illustration purposes only. Actual product may be different.
$5,440.00
$5,440.00
Sale Sold out
MSRP: $5,532.00
Shipping calculated at checkout.
  • Intel Xeon W5-3423 12-core processor (2.1 GHz base, 4.2 GHz turbo)
  • 16GB DDR5 ECC memory, expandable up to 512GB
  • 512GB M.2 PCIe NVMe SSD for high-speed storage
  • NVIDIA T400 workstation GPU with 4GB GDDR6
  • Enterprise-grade security: TPM 2.0, self-encrypting drives, HP Sure Suite
  • Wide expandability: PCIe Gen 4/5 slots, RAID 0/1 support, dual LAN and Wi-Fi 6

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Ideal for professional workloads requiring reliability, with ECC DDR5 RAM and workstation-grade Xeon processor.
  • Expandability-ready with multiple PCIe slots, RAID configuration support, and scalable memory/storage options.
  • Comprehensive built-in security features (TPM, Secure Boot, HP Sure Suite) for enterprise-grade data protection.

Product Overview

The HP Z6 G5 Workstation is designed to deliver remarkable performance for demanding workloads, featuring a 12-core Intel Xeon W5-3423 processor and 16GB ECC DDR5 memory. Its 512GB PCIe NVMe SSD and NVIDIA T400 (4GB GDDR6) graphics card cater to high-efficiency content creation and engineering applications. Expansion-ready with PCIe slots and RAID support, it also includes advanced enterprise security features such as TPM 2.0, SED, and HP Sure Start. Connectivity options like Wi-Fi 6, Bluetooth 5.3, USB-C, and dual LAN ensure flexibility in any IT environment. Energy Star compliance and a 3/3/3 limited warranty further enhance ROI.

Specifications

Product Overview
System Type Workstation
Model HP Z6 G5 Workstation Desktop PC
Form Factor Tower
Processor Type Intel Xeon W5-3423
Number of Cores 12-Core
Processor Clock Speed 2.1 GHz
Max Turbo Frequency 4.2 GHz
Cache Memory 30 MB Smart Cache
Chipset Intel W790
RAM Installed 16 GB DDR5 ECC
RAM Max Supported 512 GB
RAM Speed 4800 MHz
Storage Type PCIe NVMe SSD
SSD Capacity 512 GB
Optical Drive None
RAID Support RAID 0, 1
Graphics Processor NVIDIA T400 (4 GB GDDR6)
Audio Realtek ALC3205-CG
Operating System Microsoft Windows 11 Pro
Power Supply 1,125 W
Power Supply Efficiency 90%
Keyboard HP USB 320K Keyboard
Mouse HP Wired 320M Mouse
Weight 28.2 lbs.

Wireless Features
Wireless Standards Wi-Fi 6 (IEEE 802.11ax)
Bluetooth Version Bluetooth 5.3

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
Energy Star Compliant Yes

Advanced Security Features
Security Features TPM 2.0, HP Sure Start, HP Sure Recover, HP Sure Click, HP Sure Sense, HP Sure Run, HP Sure Admin, HP BIOSphere, Secure authentication, Full volume encryption, Self-Encrypted Drives, HP Secure Erase, Kensington lock slot, HP Platform Certificate

Interfaces
Front I/O Ports 2x USB Type-C 20Gbps; 2x USB Type-A 5Gbps; 1x headphone/microphone combo
Rear I/O Ports 6x USB Type-A 5Gbps; 1x audio-in/out; 2x RJ-45 (1 GbE AMT, 1 GbE, optional 10 GbE)
Expansion Slots 2x PCIe 4.0 x4; 2x PCIe 4.0 x16; 1x PCIe 3.0 x16; 1x PCIe 5.0 x16
Drive Bays 1x external 3.5" HDD; 2x external 9.5 mm ODD; 3x internal 3.5" HDD; 4x PCIe M.2 SSD

Physical & Environmental
Width 18.3 in
Depth 6.65 in
Height 17.5 in
Color Black

Cloud Management & Licensing
Warranty 3/3/3 limited warranty (parts/labor/onsite)
