Products Computers & Laptops HPE DL360 Gen10 SP EC-XL-H ...

HPE DL360 Gen10 SP EC-XL-H Base Server, Intel Xeon, 1U, R8L30A

VENDOR: HP Mfg Part#: R8L30A UPC#: 190017527833
1 2
Photo is for illustration purposes only. Actual product may be different.
$25,667.00
$25,667.00
Sale Sold out
MSRP: $30,624.00
Shipping calculated at checkout.
  • 1U rackmount form factor for dense deployments
  • Powered by single Intel Xeon processor with 11 MB cache
  • Supports DDR4 RDIMM memory for fast data processing
  • Eight storage bays available for flexible storage expansion
  • Includes multiple USB 3.0 ports and Ethernet networking
  • PCIe Gen4 expansion slots for high-speed peripherals

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Compact 1U design is ideal for space-constrained enterprise environments
  • PCIe Gen4 expansion allows for scalable performance upgrades over time
  • Flexible 8-bay design provides customized storage capacity to match workload needs

Product Overview

The HPE DL360 Gen10 SP EC-XL-H Base Server (R8L30A) is a 1U rackmount system featuring a single Intel Xeon processor and 11 MB cache. It supports DDR4 RDIMM memory and provides 8 drive bays for flexible storage configurations. Connectivity includes multiple USB 3.0 ports and Ethernet support. Designed for maximum efficiency, it has PCIe Gen4 expansion slots and operates within a wide power range of 100–240 VAC. Ideal for enterprise and virtualization use, it supports future-ready Intel Xeon Scalable CPUs for improved price/performance.

Specifications

Product Overview
Product Type Rackmount Server
Model HPE ProLiant DL360 Gen10
Form Factor 1U
Processor Type Intel Xeon Scalable
Number of Installed Processors 1
Maximum Supported Processors 2
Installed Cache 11 MB
Processor Socket Socket P (LGA 3647)
Supported Processor Families Second and Third Generation Intel Xeon Scalable
Memory Technology DDR4 RDIMM
Maximum RAM Supported 3 TB (with LRDIMMs)
Memory Slots 24 DIMM slots
Hot-Swap Drive Bays 8 SFF (Small Form Factor)
Power Supply Type Hot-plug redundant power supply
Power Requirements 100-120/200-240 VAC
Redundant Power Supply Support Yes

Wireless Features
Wireless Connectivity

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
EPEAT Registered No
Energy Star Certified No
Environmental Standards RoHS, ASHRAE A3/A4
Certifications FCC Class A, UL Listed, CE, VCCI, BSMI, KC

Advanced Security Features
Firmware Protection Silicon Root of Trust
Security Technologies TPM 2.0, Secure Boot, Runtime Firmware Validation
Chassis Intrusion Detection Yes (via iLO)

Interfaces
Front I/O Ports 1 x USB 3.0, 1 x iLO Service Port
Rear I/O Ports 2 x USB 3.0
Internal I/O Ports 2 x USB 3.0
Network Interface Ethernet (1 GbE or 10 GbE options via FlexibleLOM or OCP)
Data Link Protocol Ethernet
Expansion Slots Up to 3x PCIe Gen4 slots
RAID Controller Support Optional; Supports HPE Smart Array Controllers

Physical & Environmental
Dimensions (W x D x H) 17.11 x 27.8 x 1.69 in (434.6 x 707.6 x 43.0 mm)
Weight (Minimum Configuration) 16.5 kg (36.38 lb)
Operating Temperature Range 10°C to 35°C (50°F to 95°F)
Non-operating Temperature Range -30°C to 60°C (-22°F to 140°F)
Operating Humidity Range 10% to 90% (non-condensing)
Non-operating Humidity Range 5% to 95% (non-condensing)
Acoustic Power (LWAd) 6.6 B
Acoustic Pressure (LpAm) 52 dB

Cloud Management & Licensing
Integrated Management HPE iLO 5 (Standard), optional Advanced licenses
Remote Management Browser-based GUI, CLI, Redfish API
Cloud Integration Supported via HPE InfoSight and HPE OneView
Included Software HPE Intelligent Provisioning, HPE iLO Standard
Subscription Licensing Optional with iLO Advanced or OneView
