HPE External 12Gb Mini-SAS HD to Mini-SAS HD 5m AOC Cable

VENDOR: HP Mfg Part#: R7F91A
1 5
Photo is for illustration purposes only. Actual product may be different.
$1,010.00
$1,010.00
Sale Sold out
Shipping calculated at checkout.
  • 12Gb/s Mini-SAS HD to Mini-SAS HD data cable for storage applications
  • 5-meter length for extended connectivity in data center environments
  • 4-lane active optical cable for enhanced signal integrity and performance
  • Active optical design reduces EMI and supports longer reach than copper
  • TAA compliant for use in government and regulated sectors
  • Manufactured in Mexico for consistent quality control

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports 12Gb/s transmission over a 5-meter span, ideal for high-throughput enterprise storage networks
  • Active optical design minimizes interference and signal loss, optimizing performance in demanding environments
  • TAA compliance ensures eligibility for deployment in government IT infrastructures

Product Overview

The HPE External 12Gb Mini SAS HD to Mini SAS HD 5m Active Optical Cable (R7F91A) offers high-performance connectivity with 12Gb/s transfer capability and Mini-SAS HD connectors on both ends. Designed for enterprise-level storage solutions, this 5-meter active optical cable ensures minimal signal loss and low electromagnetic interference. TAA compliance and manufacture in Mexico further enhance its suitability for regulated and government environments.

Specifications

Product Overview
Product Type Active Optical Cable (AOC)
Cable Form Factor External
Cable Length 5 meters
Power Requirements Passive from connected devices
Connector Type Mini-SAS HD (SFF-8644)
Connector Gender Male to Male
Use Case Enterprise Storage Connectivity
Data Rate 12 Gbps per lane
Total Bandwidth 48 Gbps (4 lanes)

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
RoHS Compliance Yes
REACH Status Compliant
Halogen Free Yes
Certifications CSA, UL Listed
Environmental Standard WEEE Directive

Advanced Security Features
Data Encryption

Interfaces
Left Connector Type Mini-SAS HD (SFF-8644)
Right Connector Type Mini-SAS HD (SFF-8644)
Number of Lanes 4
Data Transfer Rate 12 Gbps
Interface Standard SAS 3.0
Connector Plating Gold
Connector Material Copper alloy with optical conversion
Cable Technology Active Optical

Physical & Environmental
Cable Jacket Material Thermoplastic Elastomer (TPE)
Cable Color Black
Minimum Operating Temperature 0°C (32°F)
Maximum Operating Temperature 60°C (140°F)
Storage Temperature Range -40°C to 85°C (-40°F to 185°F)
Relative Humidity (Operating) 10% to 85% (non-condensing)
Cable Diameter Approximately 4.5 mm
Bend Radius 30 mm minimum
EMI/RFI Shielding Low EMI interference
Flammability Rating VW-1
