Kingston 4GB DDR3L 1600MHz DIMM CL11 Low Voltage Module

VENDOR: KINGSTON Mfg Part#: KCP3L16NS8/4 UPC#: 740617253726
1 3
Photo is for illustration purposes only. Actual product may be different.
$31.00
$31.00
Sale Sold out
MSRP: $47.00
Shipping calculated at checkout.
  • 4GB DDR3L 1600MHz memory module with single rank architecture
  • Low-power 1.35V operation for reduced energy consumption
  • 240-pin DIMM form factor compatible with standard desktop motherboards
  • CL11 CAS latency for stable performance
  • Non-ECC DRAM suitable for mainstream computing environments
  • TAA compliant and manufactured in Taiwan

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Low voltage design at 1.35V helps reduce power consumption and heat, ideal for energy-conscious installations.
  • TAA compliance makes it suitable for government and institutional deployments requiring sourced transparency.
  • Backed by Kingston’s reliability in DRAM, ensuring compatibility and consistent performance in DDR3L-supported systems.

Product Overview

The Kingston 4GB DDR3L 1600MHz Low Voltage Module offers stable performance through a Reduced 1.35V operating voltage, supporting energy efficiency and lower thermal output. It features a 240-pin DIMM form factor and a single rank architecture, optimized for desktops requiring modest expansion. Designed with CL11 CAS latency and Non-ECC DRAM technology, this module is ideal for standard computing environments. Its TAA compliance expands its suitability for government and enterprise systems.

Specifications

Product Overview
Type Desktop Memory Module
Form Factor 240-pin DIMM
Memory Technology DDR3L SDRAM
Capacity 4 GB
Memory Rank Single Rank
Voltage 1.35 V
CAS Latency CL11
Data Integrity Check Non-ECC
Buffered/Registered Unbuffered
Heat Spreader No
Power Requirements Standard 1.35V Low Voltage
Module Configuration 512M x 64
Chip Organization 8 chips (1Gbit x8)
Performance Profile JEDEC Standard

Physical & Environmental
Module Dimensions (W x H) 133.35 mm x 30 mm
Operating Temperature 0°C to 85°C
Storage Temperature -55°C to 100°C
Humidity (Operating) 10% to 90% (non-condensing)
Humidity (Storage) 5% to 95% (non-condensing)
Weight Approximately 16 grams

Cloud Management & Licensing
Cloud Management
Licensing Requirements
Bundled Software

Interfaces
Interface Type DDR3L SDRAM
Pin Count 240-pin
Bus Speed PC3L-12800 (1600 MHz)
Memory Clock Speed 1600 MHz
Memory Bandwidth 12.8 GB/s
Compliance Interface JEDEC DDR3L

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
RoHS Compliant Yes
WEEE Compliant Yes
Halogen Free Yes
Certification Standards JEDEC, RoHS
UPC 740617253726
Manufacturer Part Number KCP3L16NS8/4
