Lenovo 1U 18 C19/C13 48A 3P WYE PDU ETL Power Distribution Unit

VENDOR: LENOVO Mfg Part#: 4PU7A81117
1 3
Photo is for illustration purposes only. Actual product may be different.
$5,435.00
$5,435.00
Sale Sold out
MSRP: $5,528.00
Shipping calculated at checkout.
  • 1U rack-mountable form factor for compact installation
  • Provides 18 C19/C13 power interfaces for diverse equipment
  • 48A power capacity across 3-phase WYE input
  • ETL-certified for safety and compliance
  • Supports scalable power delivery for data centers

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Compact 1U design maximizes rack space in dense server setups
  • 18 C19/C13 connectors enable flexible power deployment across mixed device ecosystems
  • ETL certification ensures safety and operational reliability in mission-critical environments

Product Overview

The Lenovo 1U 18 C19/C13 S&M 48A 3P WYE PDU ETL delivers efficient power distribution in high-density server environments. Its 1U form factor offers a compact design for rack integration, while C19 and C13 connectors provide broad compatibility. Built to support 48 amps in a three-phase WYE configuration and ETL-certified, it meets enterprise-level power and safety requirements.

Specifications

Product Overview
Product Type Power Distribution Unit (PDU)
Form Factor 1U Rack-mountable
Mounting Orientation Horizontal
Weight 5.44 kg (12 lbs)
Power Rating 48A
Phase Type Three-phase WYE
Voltage Range 200-240V AC
PDU Type Switched & Monitored

Wireless Features

Compliance & Origin
ETL Certification Yes
Compliance Standards ETL Listed to UL 60950-1, CSA 22.2 No.60950-1
RoHS Compliance Yes
TAA Compliant No
Country of Origin China

Advanced Security Features
Access Authentication Password-protected interface
Encryption Protocols HTTPS, SSH
Network Authentication Support RADIUS

Interfaces
Input Connector Type IEC 60309 3P+N+PE
Input Plug IEC 60309 60A WYE
Output Connector Type C13 and C19
Number of C13 Outlets 12
Number of C19 Outlets 6
Number of Output Connections 18
Communication Interface Ethernet (RJ-45)
Data Monitoring Protocols SNMP, HTTP, HTTPS, SSH, Telnet
Data Transfer Rate 10/100 Mbps Ethernet

Physical & Environmental
Dimensions (W x D x H) 43.8 x 27.9 x 4.4 cm (17.24 x 11 x 1.73 in)
Operating Temperature Range 0°C to 60°C (32°F to 140°F)
Storage Temperature Range -25°C to 65°C (-13°F to 149°F)
Operating Humidity 5% to 95% (non-condensing)
Storage Humidity 5% to 95% (non-condensing)
Cooling Passive
Construction Material Steel enclosure
Color Black

Cloud Management & Licensing
Remote Management Yes, via Web/CLI/SNMP
Local Display No local display, Ethernet-only
Alert Features User-configurable alarm thresholds for voltage, current, and temperature
Management Software Compatibility Lenovo XClarity, third-party SNMP platforms
