Lenovo 2.5" PM1733A 3.84TB RI NVMe SSD U.3 PCIe 4.0 x4

VENDOR: LENOVO Mfg Part#: 4XB7A81952 UPC#: 889488632312
  • No_media_available
1 0
Photo is for illustration purposes only. Actual product may be different.
$5,039.00
$5,039.00
Sale Sold out
Shipping calculated at checkout.
  • Interface: U.3 PCIe 4.0 x4 (NVMe)
  • Drive class: Read Intensive with 1 DWPD and 7008 TB endurance
  • High data transfer rates: 7500 MBps read / 4100 MBps write
  • 4KB random IOPS: 1,600,000 read / 170,000 write
  • Advanced data protection: ECC engine, S.M.A.R.T., power loss protection
  • Compatibility: Designed for Lenovo ThinkSystem SR635/SR655 (2.5")

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Optimized for Lenovo ThinkSystem SR635 and SR655, ensuring seamless integration and compatibility.
  • Delivers exceptional read performance (7500 MBps) and low latency (25 µs), ideal for data-driven enterprises.
  • Built-in advanced protection features and hot-swap capability enhance reliability and uptime in mission-critical environments.

Product Overview

The Lenovo 2.5" PM1733A 3.84TB Read Intensive NVMe SSD is a high-performance drive optimized for enterprise-grade applications. It features the U.3 PCIe 4.0 x4 interface, offering read/write speeds up to 7500/4100 MBps and robust 4K IOPS performance. Built with TLC NAND and offering 1 DWPD endurance, it is ideal for read-intensive applications. The drive integrates hot-swap support, end-to-end data protection, and advanced error correction, ensuring data integrity and easy maintenance. It also supports Lenovo ThinkSystem SR635/SR655 servers. With a 1-year warranty and MTBF of 2 million hours, the PM1733A balances sustained performance and operational durability.

Specifications

Product Overview
Type Solid state drive - hot-swap
Form Factor 2.5"
Capacity 3.84 TB
Drive Class Read Intensive
NAND Flash Memory Type Triple-level cell (TLC)
Hardware Encryption Yes
Endurance (DWPD) 1
SSD Endurance 7008 TB
MTBF 2,000,000 hours
Internal Data Rate 7500 MBps (read) / 4100 MBps (write)
Average Latency 25 µs
Hot-Swap Support Yes
Power Consumption (Read) 17.5 Watt
Power Consumption (Write) 19 Watt

Physical & Environmental
Width 2.8 in
Depth 3.9 in
Height 0.6 in
Weight 6.7 oz
Min Operating Temperature 32 °F
Max Operating Temperature 158 °F
Min Storage Temperature -40 °F
Max Storage Temperature 176 °F
Shock Tolerance (non-operating) 1500 g @ 0.5 ms
Vibration Tolerance (non-operating) 20 g @ 10-2000 Hz

Cloud Management & Licensing
Service & Support Limited warranty - replacement - 1 year

Interfaces
Interface Type U.3 PCIe 4.0 x4 (NVMe)
Interface Details 1 x U.3 PCIe 4.0 x4 (NVMe)
Compatible Bay 2.5"
4KB Random Read IOPS 1,600,000 IOPS
4KB Random Write IOPS 170,000 IOPS

Compliance & Origin
Compliance Standards TUV GS, VCCI, BSMI, cUL, CB, IC, FCC, KC, RCM
Country of Origin
TAA Compliance
Non-Recoverable Errors 1 per 10^17

Advanced Security Features
Data Protection Features End-to-end data protection, Advanced ECC Engine, advanced power loss protection architecture, S.M.A.R.T.
