| Product Type | Riser |
| Form Factor | Proprietary internal riser card |
| Compatible Server Model | Lenovo ThinkSystem SR250 V2 |
| Supported PCIe Standard | PCIe Gen4 |
| Total PCIe Slots Provided | 2 |
| PCIe Slot Configuration | 2 x PCIe Gen4 x8 |
| Bandwidth per PCIe Gen4 x8 Slot | Up to 16 GB/s |
| Power Requirements | Powered via server motherboard riser slot |
| Hot-Swap Capability | No |
| Weight | Approx. 100 g |
LENOVO SR250 V2 x8/x8 PCIe Gen4 Riser
Photo is for illustration purposes only. Actual product may be different.
Regular price
$334.00
Regular price
Sale price
$334.00
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
- PCIe Gen4 support for high-speed data transfer
- Dual x8 slot configuration for flexible add-in card installation
- Designed specifically for Lenovo SR250 V2 systems
- System accessory classification for seamless integration
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Designed exclusively for the Lenovo SR250 V2, ensuring optimal server compatibility and performance.
- Supports Gen4 PCIe interface, enabling faster and more efficient data communication for demanding applications.
- Dual x8 configuration increases flexibility for integrating network, GPU, or storage solutions.
Product Overview
The Lenovo SR250 V2 x8/x8 PCIe Gen4 Riser enhances the I/O capabilities of compatible SR250 V2 server systems by providing dual Gen4 x8 PCIe slots. This allows integration of high-performance expansion cards for better data throughput. Its Gen4 specification ensures higher bandwidth and efficiency over previous generations, making it ideal for networking, storage, or compute add-ons. Designed for Lenovo's infrastructure, this riser ensures reliable system compatibility and seamless scalability. Note: Certain technical specifications such as COO and TAA status are not available.
Specifications
Product Overview
Physical & Environmental
| Dimensions (WxDxH) | Approx. 195 mm x 40 mm x 20 mm |
| Operating Temperature Range | 10°C to 35°C (50°F to 95°F) |
| Storage Temperature Range | -40°C to 60°C (-40°F to 140°F) |
| Operating Humidity Range | 8% to 90% (non-condensing) |
| Storage Humidity Range | 5% to 95% (non-condensing) |
| Shock (Operating) | Half-sine 2 G, 11 ms duration, 3 axis |
| Vibration (Operating) | 0.41 grms (5 to 500 Hz) |
Cloud Management & Licensing
| Remote Management Compatibility | Compatible with Lenovo XClarity Controller (XCC) |
| Licensing Required | No |
| Included Management Software | None |
Interfaces
| Interface Type | PCIe Gen4 |
| Number of PCIe Slots | 2 |
| PCIe Lane Configuration | x8/x8 |
| Slot Compatibility | Low-profile add-in cards |
Compliance & Origin
| Country of Origin | |
| TAA Compliant | |
| RoHS Compliance | Yes |
| REACH Compliance | Yes |
| WEEE Compliance | Yes |
| Certifications | CE, FCC Class A, UL |
Advanced Security Features
| Hardware Security Integration | Mechanical support only; relies on host system security features |
| Tamper Detection | No |
