Lenovo SR635/SR645 V3 7MM RAID SATA/NVMe Kit

VENDOR: LENOVO Mfg Part#: 4XH7A93166
1 3
Photo is for illustration purposes only. Actual product may be different.
$3,926.00
$3,926.00
Sale Sold out
Shipping calculated at checkout.
  • Supports AMD EPYC 9004 Series processors with up to 4.1 GHz turbo frequency
  • 1U form factor optimized for high-density server deployments
  • RAID controller supports both Serial ATA (SATA) and NVMe storage
  • Integrated front ports: USB 3.1, USB 2.0, optional VGA, diagnostics access
  • Extensive rear I/O including USB 3.1, RJ-45 1GbE, and serial options
  • TAA compliant and manufactured in Mexico

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Combines SATA and NVMe RAID flexibility to optimize storage performance in server environments.
  • Compact 1U design enables dense deployment without compromising I/O access or CPU performance.
  • TAA compliance ensures suitability for public sector and regulated enterprise deployments.

Product Overview

The Lenovo SR635 V3/SR645 V3 7MM RAID SATA/NVMe Kit delivers robust storage control in dense server infrastructures. It’s tailored for compatibility with the SR635 V3 and SR645 V3 models, integrating high-speed SATA and NVMe drive support within a 1U chassis. This RAID kit is ideal for organizations looking to consolidate workloads while maintaining storage flexibility, reliability, and performance consistency.

Powered by AMD EPYC 9004 Series processors, the system can leverage up to 4.1 GHz turbo frequency and advanced management ports for dynamic scalability. It features multiple front and rear I/O ports including USB 3.1, USB 2.0, VGA, and RJ-45 interfaces, providing comprehensive connectivity for operational and diagnostic access. The system’s physical dimensions (17.5" W x 30.1" D x 3.4" H) and TAA compliance make it suitable for government and large enterprise deployments.

Designed with high-density application deployment in mind, this kit ensures your infrastructure remains agile and competitive. Whether you're improving data center storage throughput or deploying hybrid storage arrays for virtualization, its support for RAID configurations across both SATA and NVMe drives delivers significant ROI over time.

Specifications

Product Overview
Type RAID Controller Kit
System Compatibility Lenovo ThinkSystem SR635 V3 / SR645 V3
Form Factor 1U
Processor Type AMD EPYC 9004 Series
Processor Manufacturer AMD
Maximum Turbo Frequency 4.1 GHz
Weight 38.8 kg
Power Supply Redundancy Supported (not included in kit)
Product Type Storage Accessory Kit

Wireless Features
Wi-Fi Support
Bluetooth

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
RoHS Compliance Yes
Certifications FCC, CE, CB, UL, VCCI, BSMI

Advanced Security Features
RAID Support Yes (SATA/NVMe RAID supported)
Trusted Platform Module (TPM) Optional TPM 2.0 module support
Security Monitoring Chassis intrusion detection (platform-dependent)
Encryption Support NVMe SSD self-encrypting drive (SED) supported – depending on configuration
Firmware Security Features Secure Boot, Signed Firmware, System Lockdown

Interfaces
Storage Interface Supported SATA, NVMe
Front I/O Ports 1x USB 3.1 Gen 1 (5 Gb/s), 1x USB 2.0, External diagnostics port, optional VGA port
Rear I/O Ports 3x USB 3.1 Gen 1 (5 Gb/s), 1x VGA, 1x RJ-45 1GbE management port, optional second RJ-45 management port, optional DB-9 COM port
Management Port RJ-45 1GbE for XCC remote management
Optional Management Expansion XCC 2nd remote management port via OCP slot

Physical & Environmental
Width 17.5 in (445 mm)
Depth 30.1 in (765 mm)
Height 3.4 in (86 mm)
Operating Temperature 10°C to 35°C (50°F to 95°F)
Non-Operating Temperature -40°C to 60°C (-40°F to 140°F)
Operating Humidity 8% - 85% (non-condensing)
Non-Operating Humidity 5% - 95% (non-condensing)
Acoustic Noise Level (Declared) Varies by configuration

Cloud Management & Licensing
Management Interface Lenovo XClarity Controller (XCC)
Management Features Firmware updates, system monitoring, remote console, media redirection
Optional Add-On Licensing Lenovo XClarity Advanced and Enterprise licenses available separately
