Lenovo ST650 V2 4x3.5 HDD Cage for 3.5" Chassis

VENDOR: LENOVO Mfg Part#: 4XF7A79787
1 4
Photo is for illustration purposes only. Actual product may be different.
$376.00
$376.00
Sale Sold out
Shipping calculated at checkout.
  • - Provides four additional 3.5-inch drive bays for the Lenovo ThinkSystem ST650 V2
  • - Designed specifically for chassis supporting 3.5-inch HDDs
  • - Modular accessory improves storage scalability within existing infrastructure
  • - Compatible with enterprise-class systems
  • - Product type: Drive Bay
  • - Country of origin and TAA compliance available upon request

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • - Purpose-built for Lenovo ThinkSystem ST650 V2, ensuring seamless compatibility
  • - Enables cost-effective local storage expansion without requiring additional server infrastructure
  • - Supports enterprise-grade storage needs in high-density data environments

Product Overview

The Lenovo ST650 V2 4x3.5 HDD Cage is a purpose-built drive bay accessory tailored to extend the storage capabilities of the ThinkSystem ST650 V2 server. Designed for integration with a 3.5-inch chassis, this cage supports up to four 3.5-inch hard disk drives, expanding the system’s capacity to meet growing data demands. This makes it ideal for enterprise environments seeking to optimize storage resources without deploying additional hardware.

Users benefit from Lenovo’s emphasis on modularity and scalability, gaining a cost-effective method to extend system storage for applications like file servers or backup repositories. Its certified compatibility with the ST650 V2 server reinforces seamless integration. Enterprises can request further compliance and origin details where needed to facilitate informed procurement.

Specifications

Product Overview
Product Type Drive Bay
Form Factor Internal
Compatible Chassis Type 3.5-inch ThinkSystem ST650 V2
Supported Drive Size 3.5-inch
Drive Mounting Capacity 4 drives
Supported Device Type Hard Disk Drive (HDD)
Expansion Type Hot-swap Drive Cage
Hot-Swap Support Yes
Drive Interface Supported SAS / SATA
Power Requirements Draws power from host controller/backplane
Modular Design Yes
Purpose Storage Expansion for ThinkSystem ST650 V2

Physical & Environmental
Dimensions (WxDxH) Approx. 135 x 185 x 40 mm
Weight Approx. 0.75 kg (1.65 lbs)
Material Metal and ABS plastic
Operating Temperature Range 10°C to 35°C (50°F to 95°F)
Storage Temperature Range -40°C to 60°C (-40°F to 140°F)
Operating Humidity 8% to 80% (non-condensing)
Storage Humidity 5% to 95% (non-condensing)
Shock Tolerance Operating: 6 G at 11 ms
Vibration Tolerance Operating: 0.25 G at 5-500 Hz

Cloud Management & Licensing
Software Management Required No
Licensing Requirements None
Cloud Management Support Not applicable

Interfaces
Drive Interface Types SAS 12Gb/s, SATA 6Gb/s
Backplane Interface Yes (connects to backplane)
SAS / SATA Port Count 4
Data Transfer Rate Up to 12 Gbps (SAS), 6 Gbps (SATA)

Compliance & Origin
Country of Origin
TAA Compliance
RoHS Compliance Yes
REACH Compliance Yes
WEEE Compliance Yes
Certification Standards CE, UL, FCC

Advanced Security Features
Physical Security Features Tool-less design with lock bracket support
Tamper Evidence Yes (chassis can detect unauthorized access)
RAID Support (via host controller) Yes, with compatible RAID controller in ST650 V2
