Lenovo ThinkSystem M.2 7450P 480GB NVMe SSD

VENDOR: LENOVO Mfg Part#: 4XB7A82636 UPC#: 889488634743
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,088.00
$1,088.00
Sale Sold out
Shipping calculated at checkout.
  • 480 GB M.2 SSD with PCIe 4.0 x4 NVMe interface
  • 3D TLC NAND flash technology for improved durability
  • Sequential read/write speeds of 5000 MBps / 700 MBps
  • 280,000 IOPS random read and 40,000 IOPS random write performance
  • 0.9 DWPD endurance with 2,000,000-hour MTBF for high reliability
  • SMART support and one-year service for manageability and coverage

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • High-performance NVMe PCIe Gen4 interface provides significantly better throughput and latency over legacy SATA/SAS drives
  • Designed for enterprise read-intensive workloads with superior IOPS and endurance for virtualization and data-driven applications
  • Compact M.2 22x80 form factor and hot-swap capability offer server design flexibility and reduced operational downtime

Product Overview

The Lenovo ThinkSystem M.2 7450P 480GB NVMe SSD is engineered for performance-focused enterprise applications, offering rapid data throughput and efficient system responsiveness. Built with 3D TLC NAND flash technology, this SSD leverages the Non-Volatile Memory Express (NVMe) interface over a PCIe 4.0 x4 connection, delivering up to 5000 MBps read and 700 MBps write speeds. Designed for read-intensive environments, it offers 280,000 IOPS random reads and 40,000 IOPS random writes. This M.2 22x80mm hot-swappable drive supports 0.9 DWPD, a 2M hour MTBF, and a wide thermal operating range. With SMART monitoring, RoHS compliance, and advanced NVMe optimization, it ensures predictable lifecycle management and sustained performance in modern data infrastructure.

Specifications

Product Overview
Product Type Enterprise NVMe SSD
Form Factor M.2 2280
Capacity 480 GB
Interface PCIe 4.0 x4
NAND Flash Type 3D TLC NAND
Hot Swappable Yes
Endurance (Drive Writes Per Day) 0.9 DWPD
Mean Time Between Failures (MTBF) 2,000,000 hours
SMART Monitoring Yes
Warranty 1-Year Limited Warranty

Physical & Environmental
Width 22 mm
Length 80 mm
Operating Temperature (Min) 0°C
Operating Temperature (Max) 70°C

Advanced Security Features
Data Path Protection
AES 256-bit Encryption
Power Loss Protection
Secure Erase

Additional Features
Application Class Read-Intensive
Use Case Boot drive, Caching, Read-intensive workloads
Interface Feature Details Direct PCIe x4 connectivity for reduced latency
Internal Parallelism Optimized for multi-threaded workloads
Enlarged I/O Queues Yes
Advanced NVMe Optimizations Yes
Device Model Lenovo ThinkSystem M.2 7450 PRO
Manufacturer Part Number (MPN) 4XB7A82636
UPC 889488634743

Interfaces
Interface Standard Non-Volatile Memory Express (NVMe)
Bus Type PCI Express
PCIe Version 4.0
PCIe Lanes x4
Max Sequential Read Speed 5000 MB/s
Max Sequential Write Speed 700 MB/s
Max 4KB Random Read IOPS 280,000 IOPS
Max 4KB Random Write IOPS 40,000 IOPS

Compliance & Origin
RoHS Compliant Yes
TAA Compliant Inquire
Country of Origin Inquire

Cloud Management & Licensing
Management Tool(s) ThinkSystem System Manager (via host)
Licensing Requirement None
