| Manufacturer | LG |
| Model | LSAB-U136C |
| Product Type | Direct View LED Display (DVLED) |
| Series | MAGNIT |
| Display Diagonal Size | 136 Inch |
| Display Format | 4K Ultra HD |
| Maximum Resolution | 3840 x 2160 |
| Image Aspect Ratio | 16:9 |
| Pixel Pitch | 0.7 mm |
| Brightness | 500 nits |
| Display Technology | MicroLED with Chip-on-Board (COB) |
| LED Configuration | 5x5 Module Array |
| Color Depth | Over 1 billion colors (10-bit) |
| Mount Type | Wall Mount (Basic) |
| Trim Kit | Included (Basic) |
| Usage | Business / Commercial |
| Power Consumption (Typ.) | 2,250 W |
| Power Supply | 100-240V AC, 50/60Hz |
LG LSAB-U136C MAGNIT Series 136" 4K DV LED Display, 500 nits, P0.7
Photo is for illustration purposes only. Actual product may be different.
Regular price
$529,891.00
Regular price
Sale price
$529,891.00
Unit price
per
MSRP: $662,364.00
Shipping calculated at checkout.
Couldn't load pickup availability
- 136-inch DV LED display with 4K Ultra HD (3840 x 2160) resolution
- 0.7 mm pixel pitch for ultra-fine image clarity
- 500 nits peak brightness for consistent display performance
- COB (Chip-On-Board) technology for enhanced durability and color accuracy
- TAA compliant and manufactured in South Korea
- Includes 3-year TotalCare warranty and ConnectedCare license with up to 3 days on-site service
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Delivers ultra-high-resolution 4K visuals with fine 0.7 mm pixel pitch for impactful business presentations.
- Includes 3-year TotalCare and ConnectedCare services to minimize downtime and provide expert remote diagnostics.
- COB technology and robust panel construction provide excellent durability for continuous commercial operation.
Product Overview
135.5 DIA., 118.1W X 66.4H TOTAL DISPLAY SIZE, PREMIUM OTHERS MAGNIT SERIES, LSAB, 4K (3840X2160), ULTIMATE BUSINESS DISPLAY, COB, P0.7, 500 NITS, 5X5 ARRAY; WALL MOUNT BASIC, TRIM KIT BASIC; ALSO INCLUDES THE FOLLOWING SERVICES: 3YRS TOTALCARE, 3YRS CONNECTEDCARE LICENSE AND UP TO 3 CONSECUTIVE FESS DAYSSpecifications
Product Overview
Physical & Environmental
| Width | 118.1 Inch |
| Height | 66.4 Inch |
| Diagonal Size (Actual) | 135.5 inch (3,442 mm) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Humidity (Operating) | 10% to 80% (non-condensing) |
| Bezel Width | Borderless (0 mm with COB tech) |
| Cooling Type | Fanless Natural Convection |
| Installation Orientation | Landscape |
Cloud Management & Licensing
| Remote Management | LG ConnectedCare (3-Year License Included) |
| Monitoring Platform | LG TotalCare (3-Year Service Support) |
| Cloud Features | Real-time device diagnostics, alerts, and analytics |
| Warranty | 3 Years TotalCare with Onsite FESS (up to 3 days) |
Interfaces
| Input Interface | HDMI, DisplayPort, USB |
| Controller Interface | LG Signage Box |
| Video Interface | HDMI 2.0, DisplayPort 1.2 |
| Signal Input | Digital |
Compliance & Origin
| Country of Origin | South Korea |
| TAA Compliant | Yes |
| Certifications | FCC Class A, CE, KC |
| Environmental Certification | RoHS |
Advanced Security Features
| Integrated Security | Encrypted device communication over ConnectedCare |
| Access Control | Admin/User level controls via LG Control Software |
| Malware Detection | Supported via LG monitoring platform |
