LG LSBF015 DVLED Display, 1.56mm Pixel Pitch, 768x432, 600 Nit, TAA Compliant

VENDOR: LG Mfg Part#: LSBF015-GD UPC#: 195174076262
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.56, 768X432 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
1 4
Photo is for illustration purposes only. Actual product may be different.
$6,487.00
$6,487.00
Sale Sold out
MSRP: $8,109.00
Shipping calculated at checkout.
  • 1. 1.56mm pixel pitch enabling high-resolution 768x432 output
  • 2. Brightness level up to 600 nit after calibration
  • 3. Refresh rate of 3840 Hz for smooth visual playback
  • 4. 5000:1 contrast ratio for enhanced image detail
  • 5. TAA compliant and made in Slovakia
  • 6. Wide operational temperature range from -20°C to 40°C and 10–80% humidity
View full details

Key Benefits

Eye-Insights
  • Delivers high visual clarity with 1.56mm fine pixel pitch and 600 nit brightness for demanding signage environments
  • Built to meet TAA compliance and strict enterprise procurement standards, ensuring public sector compatibility
  • Easy integration and scalability due to modular cabinet size, low depth profile, and wide power input range

Product Overview

LSBE, DVLED, P1.56, 768X432 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72

Specifications

Primary Information
Model LSBF015
Dot Pitch / Pixel Pitch 1.56 Mm
Brightness Max. Brightness (After Calibration) 600
Width 1200 Mm
Depth 675 Mm
Height 72 Mm
Display Type LED Backlight
Flat / Curved Flat
Display / Refresh Rate 3840 Hz
Image Contrast Ratio 5000:1
Power Consumption Operational Power Consumption (W/Cabinet, Max.) 428 Power Consumption (W/Cabinet, Avg.) 182 Power Consumption (W/m, Max.) 530 Watt
Power / Voltage Required 100 to 240
Weight 23 Kg
Min Operating Temperature -20C
Max Operating Temperature 40C
Humidity Range Operating 10-80% RH

Special Feature
COO SLOVAKIA
TAA compliance Yes

Power
Power / Voltage Required 100 to 240
Power Consumption Operational Power Consumption (W/Cabinet, Max.) 428 Power Consumption (W/Cabinet, Avg.) 182 Power Consumption (W/m, Max.) 530 Watt

Display
Brightness Max. Brightness (After Calibration) 600
Dot Pitch / Pixel Pitch 1.56 Mm
Display Type LED Backlight
Flat / Curved Flat
Flat / Curved Flat

UNSPSC Code
UNSPSC Code 44111511
