Products Display Screens & Monitors Display Screens & TVs LG LSBF018 DVLED Display, 6...

LG LSBF018 DVLED Display, 640x360, 1.88mm Pixel Pitch, 600 nits

VENDOR: LG Mfg Part#: LSBF018-GD UPC#: 195174076309
  • LSBE, DVLED, P1.875, 640X360 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.875, 640X360 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.875, 640X360 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
  • LSBE, DVLED, P1.875, 640X360 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72
1 4
Photo is for illustration purposes only. Actual product may be different.
$5,157.00
$5,157.00
Sale Sold out
MSRP: $6,447.00
Shipping calculated at checkout.
  • 1. Pixel pitch of 1.88 mm for high-resolution close-view applications
  • 2. Calibrated brightness of 600 nits with 5000:1 contrast ratio for vivid imagery
  • 3. Refresh rate of 3840 Hz enables smooth content rendering
  • 4. Cabinet dimensions: 1200 mm (W) x 675 mm (D) x 72 mm (H), weight: 23 kg
  • 5. Operational temperature range: -20°C to 40°C; 10–80% RH humidity tolerance
  • 6. Power-efficient design with maximum consumption of 413W and voltage input of 100–240V
View full details

Key Benefits

Eye-Insights
  • 1. High pixel density (1.88 mm) and 3840 Hz refresh rate deliver seamless visuals ideal for commercial and control room installations.
  • 2. TAA-compliant and manufactured in Slovakia, making it suitable for government and institutional use.
  • 3. Robust environmental tolerance (-20°C to 40°C) allows for reliable deployment in diverse indoor settings.

Product Overview

LSBE, DVLED, P1.875, 640X360 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72

Specifications

Primary Information
Model LSBF018
Display Type LED Backlight
Flat / Curved Flat
Display / Refresh Rate 3840 Hz
Dot Pitch / Pixel Pitch 1.88 Mm
Image Contrast Ratio 5000:1
Brightness Max. Brightness (After Calibration) 600
Power Consumption Operational Power Consumption (W/Cabinet, Max.) 413 Power Consumption (W/Cabinet, Avg.) 166 Power Consumption (W/m, Max.) 510 Watt
Power / Voltage Required 100 to 240
Width 1200 Mm
Depth 675 Mm
Height 72 Mm
Weight 23 Kg
Min Operating Temperature -20C
Max Operating Temperature 40C
Humidity Range Operating 10-80% RH
Max Resolution 640 x 360

Power
Power / Voltage Required 100 to 240
Power Consumption Operational Power Consumption (W/Cabinet, Max.) 413 Power Consumption (W/Cabinet, Avg.) 166 Power Consumption (W/m, Max.) 510 Watt

UNSPSC Code
UNSPSC Code 44111511

Display
Brightness Max. Brightness (After Calibration) 600
Display Type LED Backlight
Dot Pitch / Pixel Pitch 1.88 Mm
Flat / Curved Flat
Flat / Curved Flat

Special Feature
COO SLOVAKIA
TAA compliance Yes
