Products Display Screens & Monitors LG LSBF025-GD DVLED Display...

LG LSBF025-GD DVLED Display, 2.5mm Pixel Pitch, 600 Nit, 1200x675mm

VENDOR: LG Mfg Part#: LSBF025-GD UPC#: 195174076316
1 1
Photo is for illustration purposes only. Actual product may be different.
$3,569.00
$3,569.00
Sale Sold out
MSRP: $4,462.00
Shipping calculated at checkout.
  • 2.5mm pixel pitch for high visual clarity in large-format applications
  • 480 x 270 native resolution over 1200mm x 675mm display area
  • 600-nit max calibrated brightness and 5000:1 contrast ratio for sharp, vivid images
  • 3840 Hz refresh rate for smooth, flicker-free video playback
  • TAA compliant and manufactured in Slovakia, suitable for government use
  • Operational in wide temperature (−20°C to 40°C) and humidity (10–80% RH) ranges

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for indoor commercial and government installations requiring TAA compliance.
  • Offers high image clarity and motion performance with 2.5mm pixel pitch and 3840 Hz refresh rate.
  • Designed for operational reliability with wide environmental tolerances and a robust build.

Product Overview

LSBE, DVLED, P2.5, 480X270 RESOLUTION, ESSENTIAL 1 CLASS, TAA SERIES, SINGLE SMD, 600 NIT, 1200X675X72

Specifications

Product Overview
Product Type DVLED Display
Model LSBF025-GD
Pixel Pitch 2.5 mm
Brightness (After Calibration) 600 nit
Resolution 480 x 270
Refresh Rate 3840 Hz
Image Contrast Ratio 5000:1
Form Factor Flat
Display Technology Direct View LED (DVLED)
Backlight Type LED
Cabinet Class Essential 1
LED Type Single SMD
Weight 23 kg
Power Consumption (Max, Per Cabinet) 372 W
Input Voltage Range 100 to 240 VAC

Wireless Features
Wireless Capability

Compliance & Origin
TAA Compliant Yes
Country of Origin Slovakia
Regulatory Certifications FCC Class A, CE, UL, RoHS

Advanced Security Features
Secure Access Management Admin/Password Role-Based Access
Firmware Protection Signed Firmware Updates

Interfaces
Signal Input Type Proprietary Modular Input (via Controller)
Control Interface RS232C / RJ45 (with controller)
Input Terminal Type Supported via LED Controller (sold separately)

Physical & Environmental
Width 1200 mm
Height 675 mm
Depth 72 mm
Minimum Operating Temperature -20°C
Maximum Operating Temperature 40°C
Operating Humidity Range 10–80% RH (non-condensing)
Ingress Protection Rating IP5X (Front)
Cabinet Material Aluminum Die-casting Frame
Service Access Front Service
Cooling Method Fanless (Natural Convection)

Cloud Management & Licensing
Remote Monitoring Compatibility LG ConnectedCare
Control Software LED Assistant, SuperSign
Web-Based Management Yes (via Control Unit)
