LG LSCB-U271C 271-Inch 4K LED Display, 1.56mm Pixel Pitch

VENDOR: LG Mfg Part#: LSCB-U271C UPC#: 195174011133
1 4
Photo is for illustration purposes only. Actual product may be different.
$342,028.00
$342,028.00
Sale Sold out
MSRP: $430,018.00
Shipping calculated at checkout.
  • Ultra HD 3840 x 2160 resolution for detailed 4K visuals
  • 1.56 mm pixel pitch for fine image rendering in large formats
  • LED backlight technology with 800 nits brightness for vibrant performance
  • 5000:1 contrast ratio for deep blacks and sharp contrast levels
  • 160°/160° viewing angle for consistent image quality across wide spaces
  • TAA compliant and manufactured in South Korea for secure deployments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers pixel-precise 4K clarity with ultra-fine 1.56 mm pitch, ideal for high-definition commercial applications
  • TAA compliance and South Korean manufacturing strengthen suitability for government and enterprise procurement
  • Modular architecture sold in bulk (100 panels) ensures efficient scalability for large-scale video wall implementations

Product Overview

4K 271Inch LSCB015 1.56mm, UltraHD, 100 pcs of LSCB015-GK.AUS, 2 CVCA

Specifications

Product Overview
Product Type Direct View LED Display
Model Number LSCB-U271C
Pixel Pitch 1.56 mm
Screen Size 271 inches (diagonal)
Resolution 3840 x 2160 (4K UHD)
Display Technology LED
Brightness 800 nits
Contrast Ratio 5000:1
Viewing Angle (H/V) 160° / 160°
Cabinet Configuration 100 modules of LSCB015-GK.AUS
Power Consumption (Max) 850W per cabinet
Power Consumption (Avg) 340W per cabinet
Power Supply AC 100–240V, 50/60Hz
Lifetime (Typical) 100,000 hours

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin Republic of Korea
TAA Compliant Yes
RoHS Compliant Yes
EMC Certification FCC Class A, CE
Safety Certifications CB, cUL, KC

Advanced Security Features
Secure Access Control Yes, via network-based control
Protected Communication Yes (encrypted control protocols)

Interfaces
Input Connector Type HDMI, DisplayPort, DVI-D, CVCA (Proprietary)
Control Interface RS232C, RJ45
Output Connector CVCA link out
Module Connection Proprietary LG CVCA interface
Number of CVCA Ports 2

Physical & Environmental
Cabinet Dimensions (W x H x D) 500 × 281.3 × 65 mm (per module)
Total Display Dimensions Approximately 6.5 m x 3.7 m
Cabinet Weight 5.8 kg per module
Operating Temperature Range 0°C to 40°C
Storage Temperature Range -20°C to 60°C
Operating Humidity 10% to 90% RH (non-condensing)
Storage Humidity 10% to 90% RH
Cooling Method Natural Convection

Cloud Management & Licensing
Management Interface LG SuperSign / LED Assistant
Remote Management Yes, via Ethernet and software tools
Licensing Requirements LG software license may be required
