LG MAGNIT LSAP012-U2 DVLED Panel, P1.25, 480x270, TAA Compliant

VENDOR: LG Mfg Part#: LSAP012-U2 UPC#: 195174090718
1 4
Photo is for illustration purposes only. Actual product may be different.
$9,275.00
$9,275.00
Sale Sold out
MSRP: $11,595.00
Shipping calculated at checkout.
  • P1.25mm pixel pitch for fine image resolution
  • 480x270 panel resolution suitable for high-density displays
  • Micro COB bonded panel for improved durability and brightness
  • TAA compliant, suitable for government and institutional use
  • Signal redundancy and secure socket data connection for system reliability
  • Compatible with Megapixel Controller for integration flexibility

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • TAA compliance ensures procurement eligibility for government and institutional projects.
  • Micro COB-bonded panel delivers higher durability and excellent brightness up to 1000 nits.
  • Signal redundancy and secure data connections enhance fault tolerance and uptime in critical applications.

Product Overview

TAA MAGNIT LSAP VI Series DVLED,P1.25, 480x270 resolution, Wall type cabinet, Signal Redundancy, Main Top, Secure Socket data connection, Panel/Cabinet compatible with Megapixel Controller,, Premium others class, Micro COB - Bonded, 1000 nit brightness, 600x337.5x44.9

Specifications

Product Overview
Product Type Direct View LED (DVLED) Display Panel
Model LSAP012-U2
Series MAGNIT LSAP VI Series
Pixel Pitch 1.25 mm
Display Resolution 480 × 270
LED Packaging Technology Micro COB (Chip-on-Board)
Brightness 1000 nits
Display Type Wall-Mount DVLED Cabinet
Cabinet Configuration Main Top
Power Requirements 100–240V AC, 50/60Hz
Typical Power Consumption 180W
Maximum Power Consumption 360W
Power Redundancy Yes (Signal Redundancy Supported)

Wireless Features
Wireless Capabilities

Compliance & Origin
Country of Origin Republic of Korea
TAA Compliant Yes
Certifications EMC Class A, IEC 60950-1 / 62368-1 compliant
RoHS Compliant Yes
Regulatory Approvals FCC, CE, KC

Advanced Security Features
Signal Redundancy Yes
Data Connection Security Secure Socket Connection
Access Control Admin-level access through controller

Interfaces
Primary Input Connector Secure Socket Data Connection
Control Interface RS232 / LAN / USB (via Controller)
Recommended Controller Compatibility Megapixel Controller

Physical & Environmental
Cabinet Dimensions (W × H × D) 600 × 337.5 × 44.9 mm
Cabinet Weight 7.2 kg (approx.)
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to +60°C
Operating Humidity 10% to 80% RH (non-condensing)
Ingress Protection Rating IP50 (front), IP20 (rear)
Surface Coating Anti-Reflective Coating
Installation Type Wall-Mounted Indoor
Service Access Front Serviceable

Cloud Management & Licensing
Remote Monitoring Yes (via LG ConnectedCare or compatible platforms)
Cloud Management Supported through external controller
Software Compatibility LG SuperSign, Megapixel VR controller compatible
Licensing Required Yes, for cloud management software
