LG TAA MAGNIT LSAP012-N25 DVLED Display Cabinet, P1.25, 480x270, 1000 nit

VENDOR: LG Mfg Part#: LSAP012-N25 UPC#: 195174108789
1 1
Photo is for illustration purposes only. Actual product may be different.
$11,909.00
$11,909.00
Sale Sold out
MSRP: $14,887.00
Shipping calculated at checkout.
  • Micro COB bonded DVLED cabinet with 480x270 resolution and P1.25 pixel pitch
  • High refresh rate of 7,680Hz and 15:1 scan rate for smooth image performance
  • 1000 nit brightness for high visibility in ambient lighting conditions
  • Secure socket data connection and signal redundancy features
  • Ceiling-type format with 600x337.5x44.9 mm dimensions
  • TAA compliance and country of origin: Republic of Korea

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Delivers ultra-smooth, high-resolution visuals with a 7,680Hz refresh rate and P1.25 pixel pitch, suitable for demanding AV environments.
  • TAA compliance and Korean origin make it ideal for government and secure enterprise deployments.
  • Supports signal redundancy and secure data connection to ensure uninterrupted performance in mission-critical applications.

Product Overview

TAA MAGNIT LSAP VI F.L.A.T. Series DVLED, P1.25, 480x270 resolution, D-IC / High performance Refresh rate 7,680Hz, Scan rate 15:1 Ceiling type cabinet, Signal Redundancy, Main Bottom, Secure Socket data connection, Panel/Cabinet compatible with Megapixel Controller,, 0 class, Micro COB - Bonded, 1000 nit brightness, 600x337.5x44.9

Specifications

Product Overview
Product Type Direct View LED Display Cabinet
Display Technology Micro COB (Chip-On-Board)
Pixel Pitch 1.25 mm
Resolution per Cabinet 480 x 270
Brightness 1000 nit
LED Refresh Rate 7680 Hz
Scan Rate 15:1
Cabinet Form Factor Ceiling-type cabinet
Installation Orientation Standard / Ceiling mount
Compatibility Compatible with Megapixel VRR Controller

Physical & Environmental
Cabinet Dimensions (W x H x D) 600 x 337.5 x 44.9 mm
Cabinet Area 0.2025 m²
Weight per Cabinet 5.7 kg
Cabinet Material Aluminum Die-Cast
Module Configuration 6 modules per cabinet (3 x 2)
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Operating Humidity 10% to 90% RH (non-condensing)
Storage Humidity 10% to 90% RH (non-condensing)
Ingress Protection (Front/Rear) IP50 / IP20
Power Consumption (Max) 160 W per cabinet
Power Consumption (Avg) 65 W per cabinet
Power Supply 100-240V AC, 50/60Hz

Cloud Management & Licensing
Remote Monitoring Supported via LG ConnectedCare
Control Software Compatibility LG LED Assistant / Megapixel Controller
Calibration Method Factory Pre-calibrated with optional on-site calibration
Cloud Integration Supported with controller software

Interfaces
Signal Redundancy Yes
Signal Connector Type Secure Socket connection
Data Interface LVDS / Proprietary DVLED interface

Compliance & Origin
Manufacturer LG Electronics
Country of Origin Republic of Korea
TAA Compliance Yes
Certifications FCC Class A, CE, EMC, RoHS
Fire Protection Rating UL94 V-0

Advanced Security Features
Signal Security Features Secure Socket Data Connection
Data Redundancy Supported
Controller Compatibility Megapixel Controller with Secure Management Support
