Philips 220-Inch UHD LED Display Kit, 1.2mm Pixel Pitch

VENDOR: PHILIPS Mfg Part#: 220BDL9112L/00 UPC#: 685417542086
1 4
Photo is for illustration purposes only. Actual product may be different.
$339,505.00
$339,505.00
Sale Sold out
MSRP: $463,671.00
Shipping calculated at checkout.
  • LED Display technology for bright, color-consistent imagery
  • Massive 220-inch diagonal screen size
  • Fine 1.2mm pixel pitch suitable for close-range viewing
  • Ultra HD (UHD) resolution for sharp, lifelike detail
  • Designed for high-end commercial and professional applications

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers immersive large-scale visuals ideal for professional-grade environments
  • Ultra-fine pixel pitch ensures detailed image fidelity even from close viewing ranges
  • Backed by Philips brand, known for reliable, high-performance display solutions

Product Overview

The Philips 220-Inch UHD LED Display Kit is engineered for ultra-large format visual applications requiring uncompromising precision and clarity. Featuring a substantial 220-inch screen size and a narrow 1.2mm pixel pitch, this display provides exceptionally detailed imagery, making it well-suited for control rooms, auditoriums, and professional signage environments.

Built with LED display technology, the unit ensures vibrant brightness and color uniformity at Ultra HD resolution. The tight pixel density allows for close viewing distances, ideal for accurate data presentation. While COO and TAA compliance are not confirmed, Philips' strong industry presence supports confidence in performance and quality.

This display serves integrators and AV professionals seeking a scalable, high-definition, large-format solution for commercial or enterprise installations.

Specifications

Product Overview
Product Type LED Display Kit
Form Factor Modular Tile-Based Video Wall
Screen Size 220 Inch
Native Resolution 3840 x 2160 (Ultra HD 4K)
Pixel Pitch 1.2 mm
Brightness (typical) 800 cd/m²
Viewing Angle (Horizontal/Vertical) 160° / 160°
Contrast Ratio (typical) 5000:1
Display Colors 16.7 Million
LED Lifetime (typ) 100,000 Hours
Power Consumption (Max) Less than 1100 W/m²
Power Consumption (Typical) Less than 360 W/m²
Voltage Range AC 100–240 V, 50/60 Hz
Weight (Total System) Approx. 600 kg

Wireless Features
Wireless Connectivity Not supported

Compliance & Origin
Country of Origin
TAA Compliance
Certifications CE, FCC Class A, RoHS

Advanced Security Features
Secure Access Options Password-protected configuration access
Encryption Support No native security encryption

Interfaces
Input Connections HDMI, DVI, DisplayPort (via LED controller)
Control Interface Ethernet (RJ45), USB (for configuration)
Signal Input Type Digital
Data Transmission Via LED Controller / Scaler
Video Wall Control Compatible with Philips LED Video Processor

Physical & Environmental
Module Resolution 480 x 270 per tile
Module Dimensions (W x H) 609.92 x 342.72 mm
Cabinet Size (W x H) 609.92 x 342.72 mm per unit
Total Dimensions (W x H) 4879 x 2744 mm (approx)
Depth (without mounting) Approx. 80 mm
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Operating Humidity 10% to 80%, non-condensing
Cooling Type Forced Air Cooling
Mounting Type Wall Mount / Stacking Frame (optional)

Cloud Management & Licensing
Remote Management Via Philips LED Controller Software
Control Software Compatibility Philips ActiveVideo or compatible LED control software
Built-In Controller No (requires external LED controller)
Included Licenses None – sold separately
